Yokogawa ANB10D-420 S2 Product Overview
The Yokogawa ANB10D-420 S2 is a high-performance signal conditioner designed for industrial automation and process control applications. It ensures accurate signal conversion, isolation, and transmission, making it suitable for harsh environments where reliability is critical.
Product Specifications
The ANB10D-420 S2 features robust construction and precise signal processing capabilities. Below are the detailed technical parameters:
| Parameter | Specification |
|---|---|
| Input Signal | 4-20 mA DC |
| Output Signal | 4-20 mA DC |
| Power Supply | 20-130 V AC/DC or 100-240 V AC/DC (selectable) |
| Isolation | Input/Output/Power: 2.5 kV AC |
| Accuracy | ±0.1% of span |
| Operating Temperature | -20°C to +60°C |
| Ambient Humidity | 10-90% RH (non-condensing) |
| Dimensions | 482.6 × 221.5 × 205 mm |
| Weight | 10 kg |
| Mounting | DIN rail mountable |
| Certifications | CE, UL, IEC 61010 |
Applications
The ANB10D-420 S2 is widely used in industries requiring precise signal conditioning and isolation, including:
-
Process Control Systems – Ensures stable signal transmission in chemical and petrochemical plants.
-
Power Generation – Used in monitoring and control loops in power plants.
-
Oil & Gas – Provides reliable signal conversion in hazardous environments.
-
Water Treatment – Maintains accuracy in flow and pressure monitoring systems.
-
Manufacturing Automation – Integrates with PLCs and DCS for industrial automation.
Product Advantages
-
High Accuracy – ±0.1% precision ensures reliable signal processing.
-
Robust Isolation – 2.5 kV AC isolation protects against electrical noise and surges.
-
Wide Power Supply Range – Supports both low and high voltage inputs.
-
Compact Design – DIN rail mounting saves space in control panels.
-
Durability – Operates reliably in extreme temperatures and humidity.
-
Compliance with Standards – Meets CE, UL, and IEC safety requirements.
Frequently Asked Questions (FAQ)
-
What is the input signal range of the ANB10D-420 S2?
-
It accepts a 4-20 mA DC input signal.
-
-
Can this signal conditioner be used in hazardous areas?
-
No, it is not intrinsically safe but is suitable for general industrial environments.
-
-
What is the isolation voltage between input and output?
-
2.5 kV AC isolation is provided between input, output, and power supply.
-
-
Does it support reverse polarity protection?
-
Yes, the device includes reverse polarity protection.
-
-
What is the operating temperature range?
-
It operates between -20°C to +60°C.
-
-
Is the ANB10D-420 S2 DIN rail mountable?
-
Yes, it is designed for easy DIN rail installation.
-
-
What certifications does this product have?
-
It is certified under CE, UL, and IEC 61010 standards.
-
-
Can it handle both AC and DC power supplies?
-
Yes, it supports 20-130 V AC/DC or 100-240 V AC/DC (selectable).
-
-
What is the typical response time of this signal conditioner?
-
The response time is typically less than 500 ms.
-
-
Is calibration required after installation?
-
Factory calibration is sufficient for most applications, but field calibration can be performed if needed.
-
