Yokogawa ANT411-5F ESB Bus Repeater Module

Product Introduction

The Yokogawa ANT411-5F ESB Bus Repeater Module is designed to extend and enhance communication across the ESB (Extensible Serial Bus) network in industrial automation systems. It ensures reliable signal transmission over long distances and supports robust data integrity in complex process control environments. The module is compatible with the Yokogawa CENTUM VP system and provides seamless integration with other ESB components.

Product Advantages

• Extended Communication Range: Enhances signal reach across long distances without degradation.

• High Reliability: Maintains stable communication even in electrically noisy industrial environments.

• Plug-and-Play Compatibility: Fully compatible with Yokogawa ESB networks and other CENTUM VP modules.

• Compact Design: Small footprint allows installation in constrained spaces.

• Robust Error Handling: Automatically detects and isolates communication errors to prevent network disruptions.

• Easy Maintenance: LED indicators provide clear status information for quick diagnostics.

Technical Specifications

Product Applications

• Industrial process control networks requiring long-distance communication.

• CENTUM VP distributed control systems needing reliable bus repeaters.

• Plants with multiple ESB segments requiring signal amplification.

• Environments with high electromagnetic interference where communication reliability is critical.

• Remote module integration in chemical, petrochemical, or energy industries.

FAQ

1. Q: What is the maximum communication distance supported by the ANT411-5F?
   A: The module extends ESB communication up to 1 km per repeater segment, depending on cable type.

2. Q: Can the ANT411-5F be used with non-Yokogawa ESB devices?
   A: It is designed primarily for Yokogawa ESB networks; compatibility with non-Yokogawa devices is not guaranteed.

3. Q: How many devices can be connected downstream of a single ANT411-5F module?
   A: Up to 32 ESB devices can be connected per repeater module.

4. Q: Does the module support hot-swapping?
   A: No, power must be turned off before installing or removing the module.

5. Q: How does the module indicate communication errors?
   A: Fault LED indicators illuminate when a network error or bus failure is detected.

6. Q: Can multiple ANT411-5F modules be daisy-chained?
   A: Yes, multiple repeaters can be used to extend the ESB network further, maintaining proper bus termination.

7. Q: What type of cables should be used for optimal performance?
   A: Shielded twisted-pair cables with proper grounding are recommended to minimize noise.

8. Q: Is the module compatible with CENTUM VP R6 and later versions?
   A: Yes, the ANT411-5F is fully compatible with CENTUM VP R6 and newer system versions.

9. Q: How is the module powered, and is there redundancy support?
   A: It is powered by 24 VDC; redundancy can be achieved via external power arrangements, not built into the module.

10. Q: Does the module support automatic error correction?
    A: Yes, it supports basic ESB error detection and isolation to prevent network-wide disruptions.
