Product Overview
The Yokogawa ANT512-5F Fiber Optic Bus Slave Module is a high-performance communication interface designed for distributed control systems (DCS) that utilize fiber optic networks. This module serves as a slave device in the control network, enabling reliable and high-speed data transmission over long distances with minimal signal degradation.
Key Features
-
High-speed fiber optic data transmission
-
Excellent noise immunity and signal integrity
-
Supports long-distance communication between DCS nodes
-
Designed for use in Yokogawa CENTUM and other control systems
-
Compact, modular design for efficient space utilization
-
Hot-swappable for easy maintenance and system upgrades
-
LED indicators for communication and status monitoring
-
Rugged construction suitable for industrial environments
Technical Specifications
| Item | Specification |
|---|---|
| Manufacturer | Yokogawa |
| Part Number | ANT512-5F |
| Product Type | Fiber Optic Bus Slave Module |
| Function | Communication interface between control nodes via fiber optics |
| Transmission Medium | Multimode fiber optic cable |
| Transmission Speed | Up to 1 Mbps |
| Transmission Distance | Up to 5 km (depending on fiber type) |
| Communication Type | Duplex optical data link |
| Optical Connector Type | ST-type or equivalent |
| Power Supply | 24 V DC nominal |
| Current Consumption | 200 mA (typical) |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | –20 °C to +70 °C |
| Humidity | 5–95% RH (non-condensing) |
| Mounting Type | Rack-mounted (for Yokogawa subsystem) |
| Dimensions | 130 × 100 × 40 mm |
| Weight | 0.5 kg |
| Compatibility | Yokogawa CENTUM and N-IO series systems |
Industry Applications
-
Distributed Control Systems (DCS) networking
-
Oil and gas plants
-
Petrochemical and refining operations
-
Power generation and utilities
-
Water treatment facilities
-
Manufacturing automation systems
Frequently Asked Questions (FAQ)
Q1: What is the function of the ANT512-5F module?
It acts as a fiber optic communication slave interface in Yokogawa control systems.
Q2: What communication medium does it use?
It uses a fiber optic link for high-speed and noise-immune data transmission.
Q3: How far can the ANT512-5F transmit data?
It supports distances up to 5 km depending on the type of optical fiber used.
Q4: Is this module compatible with Yokogawa CENTUM systems?
Yes, it is designed for integration with CENTUM and compatible subsystems.
Q5: What type of optical connectors does it use?
It uses ST-type fiber connectors or equivalent.
Q6: Can the module be replaced without shutting down the system?
Yes, it supports hot-swapping for convenient maintenance.
Q7: Does the module provide any status indicators?
Yes, it includes LED indicators for communication and status monitoring.
Q8: What is the recommended operating temperature range?
The module operates reliably between 0 °C and +55 °C.
