Yokogawa ATR8S-10 Pressure Clamp Terminal Block

Manufacturer:Yokogawa

Product Number:ATR8S-10

Product Type:Pressure Clamp Terminal Block

Origin:Japan

Dimensions:114 x 32.6 x 60.5 mm

Weight:0.2 kg

Views:148

Payment Methods:T/T, PayPal, Western Union

Condition:New & In Stock

Shipping Port:Xiamen, China

Warranty:1 Year

Lead Time:1-3 Working Days

Certificate:COO

Courier partners:DHL, UPS, TNT, FedEx and EMS.

Business hours:7*24


  • Product Details
  • FAQs
  • Related
  • Contact Us
  • Packing & Delivery
  • Product Ratings
Company Information
E-mail [email protected]
Mobile +8613666033393
Whatsapp +8613666033393
WeChat 13666033393
Add Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Yokogawa ATR8S-10 Pressure Clamp Terminal Block

Product Introduction

The Yokogawa ATR8S-10 Pressure Clamp Terminal Block is a robust and high-precision terminal solution designed for secure and efficient electrical connections in industrial automation systems. This product provides an innovative pressure clamp connection method, eliminating the need for screw tightening and reducing the risk of loose connections under harsh environmental conditions.

As part of Yokogawa’s advanced terminal series, the ATR8S-10 ensures reliable electrical contact, fast installation, and easy maintenance. It is specifically engineered to withstand vibrations, temperature fluctuations, and high electrical loads, making it ideal for Distributed Control Systems (DCS), PLC panels, and process automation applications in demanding industries such as oil & gas, petrochemical, and power generation.


Product Specifications

Parameter Description
Model ATR8S-10
Type Pressure Clamp Terminal Block
Connection Type Pressure clamp (tool-free connection)
Number of Terminals 8 points (multi-core conductor support)
Rated Voltage 250 V AC/DC
Rated Current 10 A
Insulation Resistance ≥ 100 MΩ at 500 V DC
Dielectric Strength 1500 V AC for 1 minute
Supported Wire Size 0.5 mm² – 2.5 mm²
Material Flame-retardant polyamide housing, copper alloy contacts
Temperature Range -20°C to +60°C
Humidity 10%–90% RH (non-condensing)
Mounting Method DIN rail or panel-mounted
Certifications CE, RoHS, UL
Dimensions 114 x 32.6 x 60.5 mm
Weight 0.2 kg
