The Yokogawa AVR10D-Q21020 Duplex V-net Router is a high-performance communication module designed for reliable data transfer and redundancy within Yokogawa’s CENTUM VP and ProSafe-RS control systems. This duplex router is specifically developed to support V-net/IP networks, ensuring robust and secure communication across process automation environments. Its duplex configuration allows for high availability, fault tolerance, and system stability, which are critical in industrial automation where uninterrupted operation is a must.
The AVR10D-Q21020 is widely used in large-scale distributed control systems (DCS) to link controllers, operator stations, and engineering workstations while maintaining seamless network integrity. It is designed to operate under rigorous industrial conditions, offering both durability and long-term reliability.
Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | AVR10D-Q21020 Duplex V-net Router |
| Function | Duplex communication router for V-net/IP networks |
| Supported Network | V-net/IP (Gigabit Ethernet) |
| Redundancy | Duplex mode with automatic failover |
| Data Throughput | Up to 1 Gbps |
| Communication Protocols | TCP/IP, V-net/IP |
| Dimensions | 482.6 x 132.5 x 169 mm |
| Weight | 5.8 kg |
| Power Supply | 24 V DC (typical), redundant power support |
| Operating Temperature | 0 °C to +55 °C |
| Installation | Rack-mountable, designed for control system cabinets |
Product Applications
-
Oil and Gas refineries
-
Power generation plants
-
Chemical and petrochemical industries
-
Pharmaceutical production facilities
-
Water treatment plants
-
Large-scale manufacturing automation
Product Advantages
-
High Reliability: Duplex redundancy ensures continuous operation even in the event of a failure.
-
Seamless Integration: Fully compatible with Yokogawa’s CENTUM VP and ProSafe-RS systems.
-
Secure Data Communication: Supports encrypted and reliable communication within V-net/IP networks.
-
High-Speed Performance: Gigabit data throughput ensures fast communication for large-scale operations.
-
Scalability: Designed for easy expansion to support growing network infrastructures.
-
Industrial Durability: Robust design suitable for demanding industrial environments.
FAQ
Q1: What is the primary role of the AVR10D-Q21020 in a control system?
A1: Its main role is to serve as a duplex communication router, ensuring secure, redundant, and high-speed communication between system components over the V-net/IP network.
Q2: Does the AVR10D-Q21020 support redundancy?
A2: Yes, it supports duplex redundancy, providing automatic failover to maintain continuous communication in case of module or network failure.
Q3: Which control systems is this router compatible with?
A3: It is fully compatible with Yokogawa’s CENTUM VP and ProSafe-RS systems.
Q4: Can the AVR10D-Q21020 be installed in existing system cabinets?
A4: Yes, it is designed to be rack-mounted and fits seamlessly into standard system cabinets used in process industries.
Q5: What type of network protocol does it use?
A5: It uses V-net/IP over Gigabit Ethernet, supporting TCP/IP protocols for industrial communication.
Q6: How does the router handle system failures?
A6: It automatically switches to the duplex backup system in case of hardware or communication line failures, ensuring uninterrupted communication.
Q7: What is the maximum communication speed supported?
A7: It supports up to 1 Gbps communication speed.
Q8: Can it work with third-party network equipment?
A8: While primarily designed for Yokogawa networks, it can interface with third-party equipment as long as V-net/IP and TCP/IP protocols are supported.
Q9: Does it support encrypted communication?
A9: Yes, it ensures secure communication across V-net/IP networks, which is vital for critical industrial applications.
Q10: Is the AVR10D-Q21020 hot-swappable?
A10: Yes, the module is designed for hot-swappable replacement to minimize downtime during maintenance.
