Product Introduction
The Yokogawa EB402 ER Bus Interface Master Module is an advanced communication interface designed for Yokogawa’s distributed control system (DCS) architecture. Serving as a master module within the ER Bus network, EB402 ensures reliable, high-speed, and redundant communication between system controllers and field I/O devices.
This module is engineered for robust performance in mission-critical applications, offering enhanced error detection, redundancy, and real-time data processing. With its compliance to industrial standards, EB402 is a perfect solution for demanding environments such as oil & gas, power generation, petrochemicals, and large-scale process automation systems.
Product Specifications
| Parameter | Description |
|---|---|
| Model | EB402 |
| Function | ER Bus Interface Master Module |
| Communication Protocol | ER Bus |
| Transmission Mode | High-speed synchronous data exchange |
| Power Supply | 24 V DC (nominal) |
| Power Consumption | Approx. 6.5 W |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -20°C to +70°C |
| Relative Humidity | 5% to 95% RH (non-condensing) |
| Installation | Rack-mounted in system frame |
| Compliance | CE, RoHS |
| Redundancy | Yes (dual communication path) |
| Diagnostics | Self-diagnostic, Error logging, LED display |
| Firmware Update | Supported (online upgrade) |
| Dimensions (H × W × D) | 144.65 x 130 x 32.8 mm |
| Weight | 0.3 kg |
Applications
-
Process Control Systems: Reliable master interface for ER Bus communication.
-
Distributed Control Systems (DCS): Integrates remote I/O for real-time operations.
-
Safety-Critical Installations: Redundant communication for continuous system availability.
-
Oil & Gas Operations: Maintains stable data transfer in harsh process environments.
-
Power Plants: Enhances reliability in power generation control networks.
-
Chemical and Petrochemical Facilities: Ensures accurate communication for complex process control.
Product Advantages
-
High-Speed Communication: Optimized for fast and secure data exchange with minimal latency.
-
Dual Redundancy: Maintains communication integrity even during single-channel failure.
-
Enhanced Diagnostics: Built-in self-check, error detection, and LED status indication.
-
Compact Design: Saves rack space while providing high reliability.
-
Compliance with Global Standards: CE and RoHS certified for safety and environmental compliance.
-
Field Upgradability: Firmware can be updated without removing the module from operation.
FAQ
1. What is the main function of the EB402 module?
It acts as the master interface for ER Bus communication within Yokogawa’s DCS system.
2. Does EB402 support redundant communication paths?
Yes, it supports dual-channel ER Bus communication for fail-safe redundancy.
3. Can EB402 perform self-diagnostics?
Yes, it includes self-diagnostic features and provides error logging for fault isolation.
4. Is online firmware upgrade possible?
Yes, the EB402 supports online firmware updates without system shutdown.
5. How does EB402 handle communication errors?
It uses error detection and correction protocols to maintain data integrity.
6. Can EB402 interface with multiple ER Bus slaves?
Yes, it can manage multiple slaves depending on system configuration.
7. Is EB402 compatible with Yokogawa CENTUM VP systems?
Yes, it integrates seamlessly with CENTUM VP and other Yokogawa DCS solutions.
8. Does EB402 support hot-swapping?
Yes, the module can be replaced online without stopping the control system.
9. What diagnostic indicators are available?
It includes LED indicators for power, communication status, and fault detection.
10. Does EB402 comply with EMI/EMC standards?
Yes, it is designed to meet IEC EMI/EMC requirements for industrial environments.
Related Models (Same Series or Functionality)
| Model | Description |
|---|---|
| EB401 | ER Bus Interface Master Module |
| EB403 | High-Speed ER Bus Master for Large Systems |
| EB301 | ER Bus Expansion Interface |
| EB310 | Redundant ER Bus Communication Module |
| ERB100 | ER Bus Coupler for System Integration |
| EB420 | ER Bus Extended Range Master Module |
