Product Overview
The Yokogawa F3WD64-3P Input/Output (I/O) Modules are high-performance modules designed for the F3 Series control systems, providing reliable digital and analog I/O capabilities for process automation. These modules enable seamless integration of field devices, sensors, and actuators into control and monitoring systems, supporting efficient data acquisition and system control.
Key Features
-
Supports multiple digital and analog input/output channels
-
Provides reliable signal acquisition and control for field devices
-
Compatible with Yokogawa F3 Series controllers and communication modules
-
High-speed, accurate data processing for real-time control
-
Industrial-grade design for durability and stable operation
-
Simplifies system integration and expansion
Technical Specifications
| Item | Specification |
|---|---|
| Model Number | F3WD64-3P |
| Module Type | Input/Output Module |
| Compatible System | Yokogawa F3 Series Controllers |
| I/O Channels | 64 (configurable digital/analog) |
| Signal Types | Digital Input, Digital Output, Analog Input, Analog Output |
| Response Time | ≤ 1 ms (digital), ≤ 10 ms (analog) |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -20 °C to +70 °C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Power Supply | Supplied via F3 base unit |
| Mounting | DIN rail or panel mounting via base unit |
| Dimensions | 28.9 × 100 × 83.2 mm |
| Weight | 0.12 kg |
Industry Applications
-
Oil & Gas – Field device control and process monitoring
-
Power Generation – Turbine and generator monitoring
-
Chemical & Petrochemical – Continuous process automation
-
Water & Wastewater – Pump and motor monitoring
-
Manufacturing – Industrial automation and process control
Advantages
-
Provides high-speed, reliable signal acquisition and control
-
Compatible with multiple field device types and control systems
-
Industrial-grade design ensures stable operation in harsh environments
-
Simplifies system integration and expansion
-
Enhances operational efficiency and reduces maintenance requirements
Frequently Asked Questions (FAQ)
Q1: What is the primary function of the F3WD64-3P modules?
They provide digital and analog input/output capabilities for F3 Series control systems.
Q2: How many I/O channels are available?
64 channels, configurable for digital or analog signals.
Q3: What types of signals are supported?
Digital input, digital output, analog input, and analog output.
Q4: Can these modules operate in industrial environments?
Yes, they are designed for reliable operation in industrial conditions.
Q5: What is the operating temperature range?
0 °C to +55 °C.
Q6: How are the modules powered?
They are powered via the F3 base unit.
Q7: How are the modules mounted?
DIN rail or panel mounting via the base unit.
Q8: What are the dimensions?
28.9 mm × 100 mm × 83.2 mm.
Q9: What is the module weight?
Approx. 0.12 kg.
Q10: Which industries commonly use these modules?
Oil & Gas, Power Generation, Chemical & Petrochemical, Water & Wastewater, and Manufacturing.
Related Yokogawa Modules
| Model Number | Description |
|---|---|
| F3WD32-2P | 32-channel Input/Output Module |
| F3WD128-4P | 128-channel Input/Output Module |
| F3LE12-0T | Ethernet Interface Module |
| F3PU10-0S | Power Supply Module |
| F3LC01-0T | Local Communication Module |
