The Yokogawa F3XD16-3F DC Input Module is a high-performance digital input module designed for the F3 Series control systems, providing reliable DC signal acquisition from field devices. This module enables precise monitoring of process conditions and equipment status, ensuring accurate data integration into control and monitoring systems.
Key Features
-
16-channel DC digital input module
-
High-speed signal acquisition for real-time monitoring
-
Compatible with Yokogawa F3 Series controllers and I/O modules
-
Industrial-grade design ensures reliable operation in harsh environments
-
Simplifies system integration and expansion
-
Built-in protection against overvoltage and short circuits
Technical Specifications
| Item | Specification |
|---|---|
| Model Number | F3XD16-3F |
| Module Type | DC Input Module |
| Compatible System | Yokogawa F3 Series Controllers |
| Input Channels | 16 DC input channels |
| Input Voltage | 24 V DC |
| Response Time | ≤ 1 ms |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -20 °C to +70 °C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Power Supply | Supplied via F3 base unit |
| Mounting | DIN rail or panel mounting via base unit |
| Dimensions | 28.9 ×100 × 83.2 mm |
| Weight | 0.16 kg |
Industry Applications
-
Oil & Gas – Monitoring field sensors and equipment status
-
Power Generation – Turbine and generator signal acquisition
-
Chemical & Petrochemical – Process condition monitoring
-
Water & Wastewater – Pump and motor status monitoring
-
Manufacturing – Industrial automation and control systems
Advantages
-
Provides fast and accurate digital input acquisition
-
Compatible with multiple F3 Series modules for system expansion
-
Industrial-grade design ensures stable operation in harsh conditions
-
Enhances process control reliability and reduces downtime
-
Simplifies system integration for field devices
Frequently Asked Questions (FAQ)
Q1: What is the primary function of the F3XD16-3F module?
It provides 16-channel DC digital input acquisition for F3 Series control systems.
Q2: What is the input voltage range?
24 V DC.
Q3: How many channels does it support?
16 digital input channels.
Q4: Can it operate in industrial environments?
Yes, it is designed for reliable operation under industrial conditions.
Q5: What is the response time for inputs?
≤ 1 ms for fast signal acquisition.
Q6: How is the module powered?
Powered via the F3 base unit.
Q7: How is it mounted?
DIN rail or panel mounting via the base unit.
Q8: What are the module dimensions?
28.9 mm × 100 mm × 83.2 mm.
Q9: What is the module weight?
Approx. 0.16 kg.
Q10: Which industries typically use this module?
Oil & Gas, Power Generation, Chemical & Petrochemical, Water & Wastewater, and Manufacturing.
