The Yokogawa NFSB100-S00 is a dedicated bus repeater module designed to extend the communication range and improve signal integrity within industrial automation networks. It acts as a vital link to boost and regenerate bus signals, ensuring seamless and reliable data transmission over longer distances without degradation. This module is tailored for use in Yokogawa’s distributed control systems (DCS), facilitating efficient communication among multiple control and field devices.
Built with robust components and a compact design, the NFSB100-S00 offers dependable performance in harsh industrial environments. Its ability to maintain signal quality across extended bus lines significantly reduces communication errors and system downtime. This makes it an essential component in large-scale process control applications where maintaining high communication quality is critical.
Product Specifications
| Parameter | Specification |
|---|---|
| Model Number | NFSB100-S00 |
| Module Type | Bus Repeater Module |
| Communication Protocol | Proprietary Yokogawa Bus |
| Number of Ports | 2 |
| Power Supply | 24 V DC |
| Operating Temperature | -10°C to 55°C |
| Storage Temperature | -25°C to 70°C |
| Dimensions (W x H x D) | 130 x 142.5 x 32.8 mm |
| Weight | 0.3 kg |
| Mounting | DIN Rail |
| Isolation Voltage | 1500 V AC |
| Connector Type | Screw Terminal Block |
Product Applications
The NFSB100-S00 bus repeater module is widely used in various industrial sectors where distributed control and process automation are essential. Its primary applications include:
-
Distributed Control Systems (DCS): Extends the communication range between controllers and remote field devices.
-
Process Automation: Ensures uninterrupted data flow across extended sensor and actuator networks.
-
Power Plants: Supports long-distance communication between control rooms and field equipment.
-
Oil & Gas Industry: Maintains communication integrity in large pipeline monitoring systems.
-
Water and Wastewater Treatment: Facilitates data transmission across expansive plant facilities.
-
Manufacturing Facilities: Improves network stability in complex production lines with multiple control nodes.
Its ability to regenerate signals and maintain communication reliability makes the module indispensable in any environment requiring consistent data transfer over long cable distances.
Product Advantages
-
Signal Integrity Enhancement: Regenerates and amplifies bus signals to prevent degradation over long distances.
-
Compact Design: With dimensions of 130 x 142.5 x 32.8 mm and weight of only 0.3 kg, it fits neatly into standard control panels.
-
Robust Construction: Designed to withstand industrial vibrations, temperature variations, and electrical interference.
-
Easy Installation: DIN rail mounting and screw terminal connectors simplify wiring and setup.
-
Wide Operating Range: Operates reliably in temperatures from -10°C to 55°C, suitable for most industrial environments.
-
High Isolation Voltage: 1500 V AC isolation ensures protection from electrical surges and faults.
-
Energy Efficient: Low power consumption with 24 V DC supply reduces overall system energy use.
-
Enhanced Network Reliability: Reduces communication errors, improving overall system uptime.
-
Seamless Integration: Fully compatible with Yokogawa’s bus communication standards and DCS products.
-
Global Support: Backed by Yokogawa’s worldwide service and support network for maintenance and troubleshooting.
Frequently Asked Questions (FAQ)
-
What is the primary function of the NFSB100-S00?
It serves as a bus repeater to extend communication range and maintain signal quality. -
Which communication protocol does this module support?
It uses Yokogawa’s proprietary bus communication protocol. -
How many ports does the module have?
The NFSB100-S00 has two communication ports. -
What is the operating temperature range?
The module functions reliably between -10°C and 55°C. -
Can this module be mounted on standard DIN rails?
Yes, it is designed for easy DIN rail mounting. -
What kind of connectors are used?
It uses screw terminal blocks for secure wiring. -
What is the weight and size of the module?
It weighs 0.3 kg and measures 130 x 142.5 x 32.8 mm. -
Does the module provide electrical isolation?
Yes, it offers 1500 V AC isolation voltage. -
Is the module compatible with other Yokogawa DCS components?
Yes, it is fully compatible with Yokogawa’s distributed control systems. -
What support options are available for installation or troubleshooting?
Yokogawa offers global technical support and service for this product.
