Yokogawa ​NFTC5S-00 Pressure Clamp Terminal Block for Digital

Product Introduction

The Yokogawa NFTC5S-00 Pressure Clamp Terminal Block for Digital is a high-performance connection module designed for secure and efficient wiring of digital input/output signals. Engineered with a 32-channel configuration and a dedicated connector, this terminal block provides a reliable interface between field wiring and Yokogawa control systems. Its pressure-clamp mechanism ensures a vibration-resistant, maintenance-free connection, reducing installation time and improving long-term reliability. Built for rugged industrial applications, the NFTC5S-00 is ideal for demanding automation environments where stable digital signal transmission is critical.

Technical Specifications

Applications

• Distributed Control Systems (DCS): Provides a reliable digital signal interface between field devices and Yokogawa DCS modules.

• Factory Automation: Handles dense digital I/O wiring for production lines and robotic systems.

• Power Generation: Connects status and control signals from turbines, generators, and auxiliary equipment.

• Oil & Gas Processing: Supports complex digital signaling in high-vibration and hazardous industrial settings.

• Building Automation: Interfaces sensors, alarms, and actuators for large-scale facilities management.

• Test and Measurement Systems: Provides rapid, tool-free wiring changes for laboratory or industrial testing setups.

Advantages

• High Channel Density: 32-channel configuration reduces cabinet space and simplifies wiring management.

• Tool-Free Pressure Clamp: Ensures quick installation, strong contact pressure, and vibration-proof connections.

• Dedicated Connector Interface: Supports fast plug-and-play integration with Yokogawa I/O modules.

• Enhanced Reliability: Spring-clamp technology maintains consistent contact force, minimizing signal loss over time.

• Excellent Electrical Performance: High insulation and low contact resistance provide stable signal transmission.

• Wide Environmental Tolerance: Operates reliably in harsh industrial conditions with wide temperature and humidity ranges.

• Maintenance-Friendly: No need for periodic re-tightening, reducing routine maintenance costs.

• International Compliance: Meets CE, RoHS, and IEC standards for industrial safety and environmental compatibility.

FAQ

1. How many digital signals can the NFTC5S-00 accommodate?
   It supports up to 32 individual digital input or output channels in a single module.

2. What type of connector is used for module interface?
   A dedicated multi-pin connector ensures secure and fast connection to Yokogawa digital I/O modules.

3. Is any special tool required for wiring?
   No tools are needed; the spring pressure clamp allows quick and secure wire insertion and release.

4. What is the maximum allowable current per channel?
   Each channel can carry up to 2 A continuously while maintaining low contact resistance.

5. How does the pressure clamp maintain connection stability under vibration?
   The spring mechanism provides constant pressure, preventing loosening even in high-vibration environments.

6. Can the terminal block handle mixed AC and DC signals?
   Yes, it supports 24 V DC nominal and up to 250 V AC maximum, suitable for diverse digital applications.

7. What is the rated dielectric strength of the terminal block?
   The unit withstands 1500 V AC for one minute between contacts and ground for safety assurance.

8. How is insulation resistance tested and rated?
   It provides ≥100 MΩ at 500 V DC, ensuring high-quality signal isolation.

9. Is the module compatible with standard DIN rail systems?
   Yes, it supports both 35 mm DIN rail and direct panel mounting.

10. Does the NFTC5S-00 require periodic maintenance?
    Routine maintenance is minimal since the pressure clamp maintains a stable connection without retightening.
