Product Introduction
The Yokogawa PW504 is a robust and high-performance power supply module designed to meet the needs of industrial and automation systems. As part of the PW500 Series, it offers reliable and stable DC power delivery in a compact design. The PW504 module ensures that critical control systems, sensors, and instrumentation continue to operate without interruption, making it ideal for demanding environments.
This power supply module provides an output of 24 V DC and is built to accommodate a wide range of industrial applications, from factory automation to process control systems. Designed for durability and efficiency, the PW504 also incorporates several protection features, ensuring the safety and reliability of both the module and the systems it powers.
In addition to its technical capabilities, the PW504 is easy to integrate into existing setups, thanks to its user-friendly design and DIN rail mounting feature. Whether you are looking to power PLCs, sensors, or controllers, the Yokogawa PW504 provides the performance and reliability required for modern industrial environments.
Product Parameters
Here are the key specifications for the Yokogawa PW504 Power Supply Module:
| Parameter | Value |
|---|---|
| Model | PW504 |
| Dimensions | 200 x 130 x 90 mm |
| Weight | 1 kg |
| Output Voltage | 24 V DC |
| Output Power | 200 W |
| Input Voltage Range | 100-240 V AC |
| Efficiency | > 85% |
| Operating Temperature | -10°C to 60°C |
| Protection | Overcurrent, Overvoltage, Thermal Shutdown |
| Cooling Method | Natural convection |
| Mounting Type | DIN Rail |
| Compliance | UL, CE, RoHS compliant |
| Input Frequency | 50/60 Hz |
Product Applications
The Yokogawa PW504 Power Supply Module is ideal for a variety of industrial and automation applications, where stable and efficient power is critical. Some key applications include:
-
Industrial Automation: The PW504 is frequently used to power programmable logic controllers (PLCs), sensors, and other critical control devices in automation systems.
-
Process Control: In industries like oil and gas, chemical, and manufacturing, the PW504 is used to power instrumentation systems that monitor and control critical processes.
-
Control Systems: It is commonly used in control panels, ensuring the stable operation of the systems within various automation and industrial control setups.
-
Testing and Calibration Equipment: The module powers equipment used in test environments to ensure accurate and stable performance, crucial for testing sensitive instrumentation.
-
Laboratory Applications: In laboratories where precision and stability are essential, the PW504 ensures that scientific instruments are consistently powered.
-
Machine Tools: It powers automated machinery and CNC machines, contributing to operational efficiency and reducing downtime.
The PW504 is a flexible and reliable solution for various industrial systems requiring constant and reliable power.
Product Advantages
The Yokogawa PW504 Power Supply Module is built with several key advantages, ensuring superior performance and reliability:
-
High Efficiency: With an efficiency rating of over 85%, the PW504 minimizes energy loss, making it a more environmentally friendly and cost-effective solution.
-
Compact Design: Despite offering powerful performance, the PW504 has a compact form factor (200 x 130 x 90 mm), which makes it easy to install even in tight spaces.
-
Reliable Power Output: The module provides a stable 24 V DC output, essential for powering sensitive industrial equipment that requires constant voltage.
-
Wide Input Voltage Range: The PW504 can accommodate an input voltage range of 100-240 V AC, providing flexibility for use in various global electrical systems.
-
Built-in Protection Features: The PW504 includes overcurrent protection, overvoltage protection, and thermal shutdown, ensuring the safety of both the module and the connected equipment.
-
Natural Convection Cooling: The power supply uses natural convection cooling, which eliminates the need for fans, ensuring quieter operation and reducing maintenance.
-
Ease of Installation: With DIN rail mounting, the PW504 can be easily installed in standard industrial control panels, saving time during setup.
-
Wide Temperature Range: The module can operate in temperatures ranging from -10°C to 60°C, making it suitable for a wide range of industrial environments.
-
Durability: Built to withstand harsh industrial environments, the PW504 ensures long-term, reliable operation.
-
Industry Standard Compliance: The PW504 meets UL, CE, and RoHS standards, ensuring it adheres to global safety and environmental regulations.
Frequently Asked Questions (FAQs)
-
What is the purpose of the Yokogawa PW504 Power Supply Module?
The PW504 provides stable 24 V DC power to various industrial and automation systems, ensuring reliable performance. -
What is the output power of the PW504?
The PW504 provides an output power of 200 W, suitable for powering control systems, sensors, and other industrial equipment. -
What input voltage range does the PW504 support?
The PW504 supports an input voltage range of 100-240 V AC, which makes it compatible with global electrical standards. -
How efficient is the PW504?
The PW504 boasts an efficiency of over 85%, which helps reduce energy consumption and minimize operational costs. -
What are the protection features of the PW504?
The PW504 includes overcurrent protection, overvoltage protection, and thermal shutdown, ensuring the safety of the system. -
What is the size of the PW504 power supply?
The PW504 measures 200 x 130 x 90 mm, making it compact and easy to install. -
How is the PW504 cooled?
The PW504 utilizes natural convection cooling, which helps keep the device cool without the need for fans. -
How is the PW504 installed?
The PW504 can be installed on a DIN rail, making it easy to integrate into control panels and industrial systems. -
What is the weight of the PW504?
The PW504 weighs 1 kg, making it lightweight and easy to handle during installation. -
Is the PW504 compliant with safety and environmental standards?
Yes, the PW504 is UL, CE, and RoHS compliant, ensuring it meets global safety, performance, and environmental standards.
Related Models
Here are six related models from the PW500 Series:
| Model | Description |
|---|---|
| PW501 | A compact power supply module providing similar output power for smaller applications. |
| PW502 | A high-efficiency power supply model with enhanced protection for industrial use. |
| PW503 | A modular version offering multiple outputs for versatile power distribution. |
| PW506 | A variant with adjustable output voltage and higher power capacity. |
| PW507 | A model with greater durability and optimized for harsh environments. |
| PW508 | A model designed for high-demand industrial systems, offering advanced monitoring features. |
