Product Overview
The Yokogawa S2BN1D-190 Interface Unit is a high-performance communication and control interface module designed for seamless integration within Yokogawa’s distributed control and safety systems. It provides a reliable connection between various field devices and control systems, ensuring precise data exchange and dependable signal processing.
Key Features
-
Reliable interface for communication between field devices and control systems
-
High electrical isolation ensuring system safety and signal integrity
-
Compact, modular design for easy system integration
-
Excellent resistance to noise and electromagnetic interference
-
Low power consumption and high operational reliability
-
Easy installation and maintenance
-
Compatible with Yokogawa’s DCS and safety platforms
Technical Specifications
| Item | Specification |
|---|---|
| Manufacturer | Yokogawa |
| Part Number | S2BN1D-190 |
| Product Type | Interface Unit |
| Function | Communication and signal interfacing between control and field devices |
| Communication Type | Digital / analog signal interface |
| Input/Output Channels | Multiple, depending on system configuration |
| Power Supply | 24 V DC nominal |
| Current Consumption | ≤ 200 mA |
| Isolation | Optical and galvanic isolation between channels |
| Operating Voltage | 18 to 32 V DC |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | –20 °C to +70 °C |
| Relative Humidity | 10–90% RH (non-condensing) |
| Mounting Method | DIN rail or system backplane mounting |
| Material | Industrial-grade, flame-retardant enclosure |
| Dimensions | 252 x 134 x 85.4 mm |
| Weight | 1.4 kg |
| Compliance | CE, RoHS |
| Applications | Control signal interfacing, communication, and data processing in DCS/SIS networks |
Industry Applications
-
Distributed Control Systems (DCS)
-
Safety Instrumented Systems (SIS)
-
Power generation and distribution facilities
-
Oil and gas control systems
-
Chemical and petrochemical processing plants
-
Water treatment and environmental monitoring
-
Manufacturing and automation systems
Frequently Asked Questions (FAQ)
Q1: What is the main function of the S2BN1D-190 Interface Unit?
It serves as a communication interface between Yokogawa control systems and connected field devices.
Q2: Is this module compatible with Yokogawa DCS platforms?
Yes, it integrates seamlessly with Yokogawa’s CENTUM and ProSafe-RS systems.
Q3: Does the unit provide electrical isolation?
Yes, it provides both optical and galvanic isolation for enhanced safety and reliability.
Q4: What is the typical operating voltage range?
The unit operates within 18 to 32 V DC, with 24 V DC as the nominal supply.
Q5: Can it be used in harsh industrial environments?
Yes, it is designed to withstand temperature, humidity, and vibration found in industrial settings.
Q6: What type of communication does it support?
It supports digital and analog communication interfaces, depending on the connected modules.
Q7: How is the S2BN1D-190 mounted?
It can be mounted using a DIN rail or system backplane.
Q8: Does it require special maintenance?
No, it is designed for low-maintenance and long-term continuous operation.
