Product Introduction
The Yokogawa SAV144-S53 is a highly reliable analog input module designed to handle a wide range of industrial and automation applications. This module is part of the SAV144 series and is intended for signal acquisition from analog sensors, converting them into digital data that can be processed by control systems. The SAV144-S53 supports voltage and current signals, making it suitable for integration with a variety of process control systems, data acquisition setups, and automation projects.
The module is designed to offer high-accuracy analog-to-digital conversion, with exceptional noise immunity and low signal distortion, ensuring that the system receives precise input for further processing. With compact dimensions and a robust build, the SAV144-S53 is suitable for installation in tight spaces and harsh environments, commonly found in industries such as oil and gas, chemical processing, and power generation.
Product Parameters
| Parameter | Value |
|---|---|
| Module Type | Analog Input Module |
| Dimensions | 130 x 124 x 32.8 mm |
| Weight | 0.29 kg |
| Signal Type | Voltage and Current Input |
| Number of Channels | 4 Channels (typically) |
| Input Range | 0 to 10 V, 4 to 20 mA |
| Conversion Resolution | 16-bit |
| Accuracy | ±0.1% of Full Scale |
| Temperature Range | -10°C to 60°C |
| Power Supply | 24 VDC |
| Mounting Type | DIN Rail |
| Input Impedance | > 1 MΩ |
Product Applications
The Yokogawa SAV144-S53 analog input module is primarily used in industrial automation systems where precise measurement and control of analog signals are critical. Its applications include:
-
Process Control Systems: Used to gather analog data from sensors such as temperature, pressure, and flow, which is then processed by the control system for decision-making.
-
Data Acquisition Systems: Perfect for converting real-world analog signals (such as voltage or current) into digital signals for further processing or analysis in data logging and monitoring applications.
-
Power Generation Plants: The module is used to interface with sensors monitoring critical parameters in turbines, generators, and auxiliary systems.
-
Chemical and Oil & Gas Industries: Used to acquire data from flow meters, level sensors, and other analog devices, providing valuable input for controlling chemical reactions, refining processes, and other industrial functions.
-
Machine Monitoring: Integrates with systems that measure vibration, pressure, or temperature to monitor the condition of machinery and ensure optimal performance.
-
HVAC Systems: Can interface with environmental control sensors to ensure proper operation of heating, ventilation, and air conditioning systems.
-
Building Automation: Used in controlling lighting, security, and other environmental systems based on real-time analog inputs.
Product Advantages
The Yokogawa SAV144-S53 offers several key advantages for users in various industrial and automation environments:
-
High-Accuracy Measurement: With a 16-bit resolution, the module provides precise conversion of analog signals into digital format, ensuring that even small variations in input signals are detected.
-
Wide Input Range: The module can handle voltage inputs from 0 to 10 V and current inputs from 4 to 20 mA, making it highly versatile and adaptable to various sensor types and control systems.
-
Signal Integrity: With robust noise immunity and low distortion, the module ensures that the analog signals are transmitted without interference, delivering accurate and reliable data for the monitoring system.
-
Compact and Efficient: The small form factor (130 x 124 x 32.8 mm) makes it suitable for installation in space-constrained areas, such as control cabinets and panels.
-
Flexibility in Integration: The module is easily integrated into existing control systems, offering high compatibility with a variety of automation platforms and protocols.
-
Wide Temperature Range: With an operating temperature range of -10°C to 60°C, it is suitable for deployment in a variety of environmental conditions, including outdoor installations and harsh industrial environments.
-
Cost-Effective: It offers an affordable solution for acquiring high-quality analog data in automation systems, making it ideal for budget-conscious projects without compromising on performance.
-
DIN Rail Mounting: The module can be easily mounted on a DIN rail, making it simple to install and maintain.
-
Low Power Consumption: Designed with energy efficiency in mind, the module operates on a 24 VDC power supply, minimizing overall system power consumption.
FAQ
-
What types of signals does the SAV144-S53 support?
The module supports voltage (0-10 V) and current (4-20 mA) signals, providing flexibility for a wide range of sensors. -
How many channels does the SAV144-S53 have?
The module typically supports 4 channels for simultaneous analog input. -
What is the accuracy of the SAV144-S53?
The module provides an accuracy of ±0.1% of Full Scale. -
What is the input range of the module?
The input range is from 0 to 10 V for voltage inputs and 4 to 20 mA for current inputs. -
What is the resolution of the module?
The module features a 16-bit resolution for accurate data acquisition. -
Can the module be used in harsh environments?
Yes, the SAV144-S53 operates in temperatures ranging from -10°C to 60°C, making it suitable for industrial and outdoor environments. -
What is the power supply requirement for the SAV144-S53?
The module requires a 24 VDC power supply. -
How is the SAV144-S53 mounted?
The module is designed for DIN rail mounting, ensuring easy installation and integration into control panels. -
What industries can benefit from using the SAV144-S53?
It is widely used in industries such as oil & gas, chemical processing, power generation, machine monitoring, and HVAC systems. -
How does the SAV144-S53 ensure signal integrity?
The module is equipped with noise immunity and low signal distortion to maintain high-quality data transmission.
