Yokogawa SBD4D-06 Product Introduction
The Yokogawa SBD4D-06 is a high-performance, industrial-grade signal conditioner designed for precise signal conversion and isolation in harsh environments. It is part of Yokogawa’s renowned SBD series, which is widely used in process control, automation, and measurement applications. The SBD4D-06 ensures reliable signal transmission, noise immunity, and electrical isolation, making it ideal for critical industrial systems.
Product Parameters
The table below provides detailed specifications for the Yokogawa SBD4D-06:
| Parameter | Specification |
|---|---|
| Input Signal | 4-20 mA DC, 0-20 mA DC |
| Output Signal | 4-20 mA DC, 0-20 mA DC (Isolated) |
| Power Supply | 24 V DC ±10% |
| Accuracy | ±0.1% of span |
| Isolation | Input/Output/Power: 1500 V AC |
| Operating Temperature | -20°C to +60°C |
| Ambient Humidity | 10% to 90% RH (Non-condensing) |
| Dimensions | 150 x 85.5 x 60 mm |
| Weight | 0.3 kg |
| Mounting | DIN rail mountable |
| Certifications | CE, UL, ATEX (for hazardous areas) |
Product Applications
The Yokogawa SBD4D-06 is versatile and suitable for a wide range of industrial applications, including:
-
Process Control Systems: Ensures accurate signal conditioning in chemical, oil, and gas industries.
-
Factory Automation: Provides reliable signal isolation in PLC and DCS systems.
-
Power Plants: Used for monitoring and control of critical parameters.
-
Water Treatment: Facilitates signal conversion in flow and level measurement systems.
-
HVAC Systems: Enhances signal integrity in temperature and pressure monitoring.
Product Advantages
The Yokogawa SBD4D-06 offers several key advantages:
-
High Accuracy: ±0.1% accuracy ensures precise signal conversion.
-
Robust Isolation: 1500 V AC isolation protects against electrical noise and surges.
-
Compact Design: DIN rail mounting saves space in control panels.
-
Wide Operating Range: Functions reliably in extreme temperatures and humidity.
-
Certified Safety: Complies with CE, UL, and ATEX standards for hazardous environments.
-
Easy Installation: Plug-and-play design reduces setup time.
Frequently Asked Questions (FAQ)
-
What is the input voltage range for the SBD4D-06?
The power supply range is 24 V DC ±10%. -
Can the SBD4D-06 be used in hazardous areas?
Yes, it is ATEX-certified for use in hazardous environments. -
What is the isolation voltage between input and output?
The isolation voltage is 1500 V AC. -
Is the SBD4D-06 compatible with other Yokogawa devices?
Yes, it is designed to integrate seamlessly with Yokogawa’s control systems. -
What is the typical response time of the SBD4D-06?
The response time is less than 100 ms. -
Can the output signal be adjusted?
Yes, the output can be configured for 4-20 mA or 0-20 mA. -
What is the operating temperature range?
It operates between -20°C and +60°C. -
Does the SBD4D-06 require calibration?
Periodic calibration is recommended for maintaining accuracy. -
Is the device DIN rail mountable?
Yes, it is designed for DIN rail installation. -
What certifications does the SBD4D-06 have?
It is certified by CE, UL, and ATEX.
