Yokogawa SSC60D-F2541 Product Documentation

Product Introduction

The Yokogawa SSC60D-F2541 is a high-performance single-loop controller designed for precise process control in industrial applications. It features advanced control algorithms, robust construction, and user-friendly operation, making it suitable for a wide range of industries, including chemical, pharmaceutical, food and beverage, and energy. The controller supports various input signals, including thermocouples, RTDs, and analog inputs, ensuring compatibility with diverse sensors and transmitters.

Product Parameters

Product Applications

The SSC60D-F2541 is widely used in industries requiring precise temperature, pressure, flow, or level control. Key applications include:

• Chemical Processing: Regulating reactor temperatures and pressure in batch processes.

• Pharmaceuticals: Maintaining strict environmental conditions in cleanrooms and storage.

• Food & Beverage: Controlling pasteurization and fermentation processes.

• Energy Management: Monitoring and optimizing boiler and HVAC systems.

• Water Treatment: Managing pH levels and flow rates in purification systems.

Product Advantages

1. High Accuracy: Advanced PID algorithms ensure stable and precise control.

2. Versatile Inputs: Supports multiple sensor types, reducing the need for additional signal converters.

3. Durable Construction: IP66-rated front panel protects against dust and water ingress.

4. Easy Configuration: Intuitive interface with programmable setpoints and alarms.

5. Reliable Communication: RS-485 Modbus RTU enables seamless integration with SCADA and PLC systems.

6. Energy Efficient: Low power consumption reduces operational costs.

Frequently Asked Questions (FAQ)

1. What is the difference between the SSC60D-F2541 and the SSC50D model?
   The SSC60D-F2541 offers enhanced communication capabilities (RS-485) and a higher protection rating (IP66) compared to the SSC50D.

2. Can the SSC60D-F2541 be used for multi-loop control?
   No, it is designed for single-loop control. For multi-loop applications, consider the Yokogawa UTAdvanced series.

3. What types of thermocouples are supported?
   It supports J, K, R, S, B, E, T, N, W, and L-type thermocouples.

4. Is the controller compatible with 4-20mA sensors?
   Yes, it accepts 4-20mA analog inputs.

5. How do I calibrate the SSC60D-F2541?
   Calibration can be performed via the front panel or through Modbus communication using Yokogawa’s dedicated software.

6. What is the maximum load capacity for relay outputs?
   The relay output supports up to 250V AC, 5A (resistive load).

7. Does it support alarm functions?
   Yes, it includes up to four programmable alarms with relay or communication triggers.

8. Can the display be customized?
   Yes, the LCD can show process values, setpoints, and bar graphs in user-defined formats.

9. What is the warranty period?
   Yokogawa provides a standard 2-year warranty for this model.

10. Is the SSC60D-F2541 suitable for hazardous areas?
    No, for hazardous environments, consider the IS-models with ATEX or IECEx certification.
