Product Overview
The Yokogawa YCB141-M010 is a dedicated 10BASE-2 coaxial communication cable designed for reliable operation within the V net infrastructure of Yokogawa’s CENTUM systems. It provides stable data transmission over a 10-meter length and is essential for seamless integration in distributed control system networks.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | YCB141-M010 |
| Cable Type | 10BASE-2 Coaxial Cable (V net) |
| Outer Diameter | Approx. Ø14.5 mm |
| Minimum Bending Radius | 50 mm |
| Operating Temperature | -20°C to +70°C |
| Cable Length | 10 m |
| Shipping Weight | 2 kg |
| Compatible Systems | CENTUM VP, CS 3000, CS 1000 |
| Option Code | /NL (CSA Non-Incendive Support) |
Applications
-
Designed for CENTUM VP, CENTUM CS 3000, and CENTUM CS 1000
-
Used in V net (10BASE-2) network infrastructure
-
Suitable for dual-redundant or single-loop communication
-
Ideal for industrial control environments
Product Advantages
-
Genuine Yokogawa quality ensures system compatibility
-
Temperature durability from -20°C to +70°C
-
Low signal attenuation over 10 meters
-
Flexible installation due to small bending radius
-
Secure coaxial transmission with BNC connectors
-
Available CSA-compliant version for hazardous areas
Frequently Asked Questions (FAQ)
Q1: What is the standard length of the YCB141-M010?
A1: 10 meters.
Q2: Which systems are supported?
A2: CENTUM VP, CENTUM CS 3000, and CS 1000.
Q3: What is the cable diameter?
A3: Approximately 14.5 mm.
Q4: Can it operate in extreme environments?
A4: Yes, it functions from -20°C to +70°C.
Q5: What is the minimum bending radius?
A5: 50 mm.
Q6: Is the YCB141 Ethernet-compliant?
A6: No, it uses the 10BASE-2 term but follows V net specs.
Q7: What is the weight for shipping?
A7: 2 kg.
Q8: Is redundant communication supported?
A8: Yes, both single and dual-redundant configurations.
Q9: Is CSA non-incendive support available?
A9: Yes, with the /NL option code.
Q10: Are custom lengths available?
A10: Yes, up to 185 m in 5 m increments.
Related YCB141 Series Models
| Model | Description | Length | Weight | Notes |
|---|---|---|---|---|
| YCB141-M001 | V net Cable (10BASE-2) | 1 m | 0.3 kg | Short link |
| YCB141-M002 | V net Cable (10BASE-2) | 2 m | 0.5 kg | |
| YCB141-M005 | V net Cable (10BASE-2) | 5 m | 1.0 kg | |
| YCB141-M020 | V net Cable (10BASE-2) | 20 m | 3.2 kg | Extended distance |
| YCB141-M050 | V net Cable (10BASE-2) | 50 m | 6.8 kg | Long run |
| YCB141-M185 | V net Cable (10BASE-2, max) | 185 m | 18 kg | Max length available |
