ABB DSAI 110 57120001-DP Product Introduction
The ABB DSAI 110 57120001-DP is a high-performance digital signal analyzer designed for industrial automation and power distribution systems. It provides precise measurement and monitoring capabilities, ensuring optimal performance in complex electrical environments. This device is widely used in energy management, grid stability, and industrial process control, offering reliability and accuracy in demanding applications.
Product Parameters
| Parameter | Specification |
|---|---|
| Model Number | DSAI 110 57120001-DP |
| Input Voltage | 110V AC/DC (range: 85-264V) |
| Frequency Range | 50/60 Hz (±10%) |
| Dimensions | 360 x 10 x 255 mm |
| Weight | 0.45 kg |
| Operating Temp. | -20°C to +70°C |
| Storage Temp. | -40°C to +85°C |
| Communication | RS-485, Modbus RTU protocol |
| Accuracy | ±0.5% of reading |
| Protection Class | IP20 |
Product Applications
The DSAI 110 57120001-DP is ideal for:
-
Industrial Automation: Real-time monitoring of machinery and equipment.
-
Power Distribution Systems: Voltage and current analysis in substations.
-
Renewable Energy: Performance tracking in solar/wind farms.
-
Data Centers: Ensuring stable power supply and load management.
-
Smart Grids: Enhancing grid reliability and fault detection.
Product Advantages
-
High Precision: ±0.5% accuracy ensures reliable data for critical decisions.
-
Robust Design: Operates in harsh environments (-20°C to +70°C).
-
Easy Integration: Modbus RTU support for seamless system compatibility.
-
Compact Size: Space-saving design for versatile installation.
-
Low Maintenance: Durable components reduce downtime.
FAQ (Frequently Asked Questions)
-
What is the operating voltage range of the DSAI 110 57120001-DP?
-
85-264V AC/DC.
-
-
Can this device be used in outdoor environments?
-
No, it has an IP20 rating and is designed for indoor use.
-
-
What communication protocols are supported?
-
RS-485 with Modbus RTU.
-
-
Is calibration required periodically?
-
Yes, annual calibration is recommended for optimal accuracy.
-
-
What is the typical response time for measurements?
-
Less than 100ms for real-time data.
-
-
Does it support firmware updates?
-
Yes, updates can be performed via the communication interface.
-
-
Can it measure harmonics?
-
No, it focuses on fundamental voltage/current parameters.
-
-
What is the warranty period?
-
2 years from the date of purchase.
-
-
Is it compatible with ABB’s automation suites?
-
Yes, it integrates with ABB Ability™ and other systems.
-
-
How is the device powered?
-
It draws power directly from the measured circuit.
-
Recommended Related Models
| Series/Related Models | Description |
|---|---|
| DSAI 110 57120002-DP | Enhanced version with harmonics analysis |
| DSAI 220 57120001-DP | 220V variant for higher voltage systems |
| DSAI 110 57120001-DN | DIN rail-mountable version |
| DSAI 110 57120001-WiFi | WiFi-enabled for wireless monitoring |
| DSAI 110 57120001-ETH | Ethernet communication support |
| DSAI 110 57120001-POE | Power-over-Ethernet capability |
