ABB DSAI 130 57120001-P DS analog input unit
- Product Details
- FAQs
- Related
- Contact Us
- Packing & Delivery
- Product Ratings
Product Introduction
The ABB DSAI 130 57120001-P is an advanced analog input interface module used in ABB’s Distributed Control System (DCS) platforms, particularly in the Advant Master and Symphony series. It plays a critical role in acquiring analog signals from various sensors and transmitting them to the control system for monitoring and control operations. This module is engineered for high accuracy, long-term reliability, and seamless integration within industrial automation environments, making it a preferred choice for large-scale process control applications.
Its compact form factor, rugged build quality, and compatibility with legacy as well as modern systems make it a highly versatile component in ABB’s extensive automation product lineup.
Product Features
-
Multi-channel analog input capability
-
High-resolution signal conversion for precise data acquisition
-
Noise-resistant design for industrial environments
-
Seamless integration with ABB Advant Master and Symphony DCS platforms
-
Long operational life and reduced maintenance requirements
-
DIN-rail mountable for easy installation
-
Field-proven reliability in continuous process industries
-
Robust diagnostic features for simplified troubleshooting
Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | DSAI 130 57120001-P |
| Manufacturer | ABB |
| Module Type | Analog Input Module |
| Input Channels | 8 Analog Channels |
| Signal Range | 0–20 mA, 4–20 mA (configurable) |
| Resolution | 12-bit |
| Input Impedance | > 250 Ohms |
| Isolation | Galvanic Isolation per Channel |
| Power Supply Voltage | 24 VDC nominal |
| Power Consumption | < 5 W |
| Operating Temperature | -10°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5%–95% non-condensing |
| Mounting Type | DIN Rail |
| Dimensions | 327.6 x 14.4 x 236.7mm |
| Weight | 0.52 kg |
Product Applications
-
Chemical and petrochemical processing plants
-
Power generation and distribution networks
-
Water and wastewater treatment facilities
-
Metallurgical and mining operations
-
Pulp and paper manufacturing lines
-
Food and beverage industrial control
-
Oil and gas instrumentation systems
-
Pharmaceutical production monitoring
Product Advantages
-
High signal integrity with galvanic isolation
-
Durable industrial-grade design for 24/7 operations
-
Backward compatibility with legacy ABB systems
-
Precise signal processing ensures better control decisions
-
Low power consumption reduces operational costs
-
Compact design saves panel space
-
Quick replacement and field installation-friendly
-
Trusted quality from ABB’s engineering excellence
Frequently Asked Questions (FAQ)
Q1: What type of signals can ABB DSAI 130 process?
A1: It can process standard analog current signals like 0–20 mA and 4–20 mA, commonly used in industrial sensors.
Q2: Is this module compatible with ABB Advant Master systems?
A2: Yes, the DSAI 130 is designed specifically for use with ABB Advant Master and Symphony DCS platforms.
Q3: How is the module mounted?
A3: It is DIN-rail mountable, simplifying installation and system expansion.
Q4: Does the module offer input channel isolation?
A4: Yes, each input channel is galvanically isolated to prevent cross-interference.
Q5: Can it be used in high-humidity environments?
A5: Yes, it operates reliably in humidity levels up to 95% non-condensing.
Q6: What diagnostic features does the DSAI 130 provide?
A6: The module includes built-in diagnostic functions to detect signal faults and wiring errors.
Q7: Is it hot-swappable?
A7: No, for safety and system integrity, power should be removed before replacing the module.
Q8: What is the expected lifespan of the DSAI 130?
A8: Under normal conditions, it can function reliably for over 10 years.
Q9: What certifications does the module carry?
A9: The module meets standard industrial certifications for safety and EMC compliance.
Q10: Can the module operate in outdoor enclosures?
A10: It is designed for indoor panels but can be used in sealed outdoor enclosures with temperature and humidity control.
Related or Same-Series Models
| Model Number | Description |
|---|---|
| DSAO 120 | Analog Output Module |
| DSBC 176 | Processor Communication Module |
| DSDI 110 | Digital Input Module (24 VDC) |
| DSDO 115 | Digital Output Module (Relay) |
| DSTA 131 | Terminal Unit for I/O Modules |
| DSAO 130 | Analog Output Module, 8 Channels |
Popular ABB Models (Recommended)
| Model Number | Description | Application |
|---|---|---|
| PM864AK01 | AC 800M Controller | Process automation |
| CI854AK01 | Profibus-DP Communication Module | Field device communication |
| AI810 | Analog Input Module 8 ch, 4-20mA | Sensor signal input |
| DO810 | Digital Output Module 16 ch, 24VDC | Actuator and relay control |
| DI810 | Digital Input Module 16 ch, 24VDC | Switch and sensor input |
| TB820 | Module Termination Unit | I/O module wiring |
Frequently Asked Questions (FAQ)
Q1: What type of signals can ABB DSAI 130 process?
A1: It can process standard analog current signals like 0–20 mA and 4–20 mA, commonly used in industrial sensors.
Q2: Is this module compatible with ABB Advant Master systems?
A2: Yes, the DSAI 130 is designed specifically for use with ABB Advant Master and Symphony DCS platforms.
Q3: How is the module mounted?
A3: It is DIN-rail mountable, simplifying installation and system expansion.
Q4: Does the module offer input channel isolation?
A4: Yes, each input channel is galvanically isolated to prevent cross-interference.
Q5: Can it be used in high-humidity environments?
A5: Yes, it operates reliably in humidity levels up to 95% non-condensing.
Q6: What diagnostic features does the DSAI 130 provide?
A6: The module includes built-in diagnostic functions to detect signal faults and wiring errors.
Q7: Is it hot-swappable?
A7: No, for safety and system integrity, power should be removed before replacing the module.
Q8: What is the expected lifespan of the DSAI 130?
A8: Under normal conditions, it can function reliably for over 10 years.
Q9: What certifications does the module carry?
A9: The module meets standard industrial certifications for safety and EMC compliance.
Q10: Can the module operate in outdoor enclosures?
A10: It is designed for indoor panels but can be used in sealed outdoor enclosures with temperature and humidity control.
Related or Same-Series Models
| Model Number | Description |
|---|---|
| DSAO 120 | Analog Output Module |
| DSBC 176 | Processor Communication Module |
| DSDI 110 | Digital Input Module (24 VDC) |
| DSDO 115 | Digital Output Module (Relay) |
| DSTA 131 | Terminal Unit for I/O Modules |
| DSAO 130 | Analog Output Module, 8 Channels |
Popular ABB Models (Recommended)
| Model Number | Description | Application |
|---|---|---|
| PM864AK01 | AC 800M Controller | Process automation |
| CI854AK01 | Profibus-DP Communication Module | Field device communication |
| AI810 | Analog Input Module 8 ch, 4-20mA | Sensor signal input |
| DO810 | Digital Output Module 16 ch, 24VDC | Actuator and relay control |
| DI810 | Digital Input Module 16 ch, 24VDC | Switch and sensor input |
| TB820 | Module Termination Unit | I/O module wiring |
