Product Introduction
The Allen Bradley 1606-XL240DR Redundant Power Supply is a high-reliability, compact power supply module designed for industrial automation systems requiring uninterrupted DC power. Its redundant design ensures continuous 24 V DC output even in case of a primary supply failure, making it ideal for critical control applications.
The 1606-XL240DR supports a wide input voltage range and features high efficiency, low ripple output, and thermal derating capabilities for operation in demanding industrial environments. It is part of the 1606-XL series, known for modular, DIN-rail mountable, and easily integrated power solutions.
Product Specifications
| Parameter | Specification |
|---|---|
| Model | 1606-XL240DR |
| Series | 1606-XL |
| Product Type | Redundant Power Supply Module |
| Output Voltage | 24 V DC |
| Rated Output Power | 240 W |
| Rated Output Current | 10 A |
| Input Voltage AC | 100–120 V AC / 200–240 V AC manual select |
| Input Voltage DC | 240–375 V DC |
| Operational Range AC | 85–132 / 176–264 V AC |
| Frequency | 47–63 Hz |
| Rated Input Current | <6 A (115 V AC) / <2.8 A (230 V AC) |
| Hold-up Time | >25 ms (AC 196 V) |
| Efficiency | Typ. 89% |
| Ripple/Noise | <30 mVPP |
| Operating Temperature | 0–70 °C (derating above 60 °C) |
| Storage Temperature | -40–85 °C |
| Dimensions (H x W x D) | 120 x 124 x 102 mm |
| Weight | 0.98 kg |
| Mounting Type | DIN-rail |
| Certifications | UL, CE, CSA |
Applications
-
Critical Automation Systems: Ensures uninterrupted 24 V DC supply for PLCs, actuators, and sensors.
-
Redundant Power Architectures: Designed for dual supply setups in process control and safety systems.
-
Industrial Control Panels: Provides stable, low-ripple power for control modules.
-
Machine Safety and Reliability: Prevents downtime in machinery requiring constant power supply.
-
Building Automation: Supports critical devices in HVAC, security, and monitoring systems.
Advantages
-
Redundant Operation: Maintains uninterrupted 24 V DC output during primary supply failure.
-
Wide Input Voltage Range: Supports 100–240 V AC and 240–375 V DC, compatible with global industrial supply variations.
-
High Efficiency: Typ. 89% efficiency reduces energy loss and heat generation.
-
Low Ripple/Noise: <30 mVPP output ensures stable operation for sensitive electronics.
-
Compact DIN-Rail Mountable Design: Saves panel space and simplifies installation.
-
Thermal Derating Capability: Operates up to 70 °C, with performance adjustment above 60 °C.
-
Industrial Certifications: UL, CE, and CSA approved for industrial safety compliance.
