Allen Bradley 1747-L542 CPU Processor Unit Module

Product Introduction

The Allen-Bradley 1747-L542 CPU Processor Unit Module is a high-performance controller within the SLC 500 Series, designed for large-scale industrial automation applications requiring extensive memory, high-speed processing, and substantial I/O capacity. It is part of the advanced SLC 5/05 family, providing deterministic and reliable control for both discrete and analog operations.

The 1747-L542 features 28K Words of program memory and 32K Words of user memory, enabling complex control programs and extensive data handling. It supports up to 4096 input points and includes 4K Words of data memory for storage of process values, system variables, and parameters. Operating over a 5–24 VDC voltage range, with a backplane current of 500 mA at 5 VDC and 175 mA at 24 VDC, the module ensures efficient power utilization and reliable operation in SLC 500 racks. This CPU is ideal for high-demand industrial environments requiring fast, deterministic control and large-scale automation integration.

---

Product Specifications

---

Applications

• Large-scale machine and process control requiring high input/output capacity

• Complex sequencing, logic, and process automation in manufacturing environments

• Data acquisition and storage with large memory and data registers

• Standalone or networked SLC 500 systems requiring deterministic and reliable control

• Industrial automation retrofits needing expanded program and user memory

• Control of multi-line processes integrating extensive digital and analog signals

---

Advantages

• High program memory (28K Words) and user memory (32K Words) for advanced applications

• Large data memory (4K Words) for process values, variables, and system parameters

• Supports up to 4096 inputs, enabling control of extensive automation systems

• Wide voltage range (5–24 VDC) ensures compatibility with industrial power supplies

• Reliable backplane current handling, 500 mA @ 5 VDC and 175 mA @ 24 VDC

• Compact, lightweight design, suitable for SLC 500 rack installations

• Seamless integration with SLC 500 modules, providing flexibility in system configuration

FAQ

1. What is the program memory of the 1747-L542?
   It provides 28K Words of program memory for complex control programs.

2. How much user memory is available?
   The module offers 32K Words of user memory for parameters, data, and configuration.

3. What is the maximum input capacity?
   It can handle up to 4096 input points.

4. How much data memory does the module include?
   The 1747-L542 provides 4K Words of data memory.

5. What voltage range does the CPU support?
   It operates over 5–24 VDC.

6. What is the backplane current rating?
   It draws 500 mA at 5 VDC and 175 mA at 24 VDC.

7. Is the 1747-L542 suitable for both discrete and analog control?
   Yes, it supports mixed-signal applications including discrete and analog I/O.

8. Can this module operate independently or does it require a network?
   It can function as a standalone CPU or as part of a larger SLC 500 network.

9. Is it suitable for continuous industrial operation?
   Yes, it is rated for continuous-duty use in industrial environments.

10. What types of applications is this CPU best suited for?
    It is ideal for large-scale process control, complex sequencing, high-speed data acquisition, and multi-line automation systems.
