Allen Bradley 1756-DHRIO ControlLogix Remote I/O Communication Interface Module

Product Introduction

The Allen-Bradley 1756-DHRIO is a ControlLogix Remote I/O (RIO) communication interface module that enables high-speed, reliable communication between a ControlLogix chassis and remote I/O devices. It provides a dual-channel interface, allowing for redundant or parallel communication paths, which ensures consistent data transfer in distributed industrial automation systems.

Designed for flexible and scalable ControlLogix networks, the 1756-DHRIO supports deterministic communication over Remote I/O networks, making it ideal for process control, manufacturing automation, and mission-critical industrial applications.

---

Product Specifications

---

Applications

• Provides dual-channel remote I/O communication for ControlLogix systems

• Enables deterministic data transfer between chassis and distributed I/O devices

• Applied in process automation, manufacturing, and batch control systems

• Supports redundant or parallel communication paths to enhance network reliability

• Ideal for distributed control architectures requiring high-speed and reliable data exchange

---

Advantages

• Dual-channel design supports redundancy or increased communication throughput

• Reliable deterministic communication ensures consistent data transfer between controllers and remote I/O

• Low backplane current minimizes energy usage while maintaining performance

• Compact module design simplifies installation in ControlLogix chassis

• Open-style mounting allows flexible industrial panel installation

• Designed for robust performance in mission-critical industrial networks

FAQ

1. What is the primary function of the 1756-DHRIO module?
   It provides dual-channel Remote I/O communication between ControlLogix chassis and distributed I/O devices.

2. How does the dual-channel design improve reliability?
   It enables redundancy or parallel communication paths, ensuring data continuity even if one channel fails.

3. Can the module handle deterministic communication?
   Yes, it provides reliable real-time communication suitable for industrial automation.

4. What type of systems is this module used in?
   It is used in distributed control systems, manufacturing automation, and process control applications.

5. Does the module support multiple remote I/O devices?
   Yes, it can interface with multiple remote I/O nodes within the ControlLogix network.

6. How is the module powered?
   It draws 1.7 mA at 5 V and 850 mA at 24 V from the backplane.

7. Is the module compatible with standard ControlLogix chassis?
   Yes, it integrates seamlessly with ControlLogix controllers and chassis.

8. Can it be used in open-style industrial panels?
   Yes, the module is rated for open-style mounting.

9. Does it generate significant heat?
   No, maximum power dissipation is 4.5 W, with thermal dissipation of 15.4 BTU/hr.

10. What are the advantages of using a DHRIO module?
    It provides high-speed, redundant, and deterministic communication for distributed ControlLogix networks.
