Product Introduction
The Allen-Bradley 1756-IF8K ControlLogix Analogue Input Module is a flexible analog input module designed for ControlLogix automation systems requiring multiple signal types and acquisition modes. It supports single-ended, differential, and high-speed differential inputs, allowing it to adapt to a wide range of industrial measurement requirements.
This module is well suited for applications that involve both standard process signals and faster-changing analog values. By offering multiple input configurations within a single module, the 1756-IF8K reduces system complexity while maintaining reliable and accurate signal acquisition.
Designed for seamless integration into ControlLogix architectures, the 1756-IF8K provides stable analog input performance for automation systems where versatility, signal integrity, and consistent data acquisition are essential.
Product Specifications
| Parameter | Details |
|---|---|
| Model | 1756-IF8K |
| Series | ControlLogix |
| Type | Analogue Input Module |
| Input Points | 8 |
| Input Configuration | 8 single-ended inputs |
| Differential Inputs | 4 |
| High-Speed Differential Inputs | 2 |
| Supported Signals | Current and Voltage |
| Connector Type | 20-pin |
| Supply Voltage | 24 VDC |
| Dimensions | 145.2 × 34.6 × 139.6 mm |
| Weight | 0.45 kg |
Applications
• Industrial Automation Systems: Collects analog data from sensors and transmitters for real-time monitoring and control.
• Mixed Signal Measurement: Supports single-ended and differential signals, allowing flexible connection of various field devices.
• High-Speed Monitoring: Differential high-speed inputs enable accurate acquisition of rapidly changing process signals.
• Machine Control Applications: Suitable for machinery requiring stable and responsive analog feedback.
• ControlLogix-Based Systems: Integrates easily into existing ControlLogix racks for centralized data acquisition.
Advantages
• Multiple Input Configurations: Supports single-ended, differential, and high-speed differential inputs in one module.
• Flexible Signal Support: Compatible with current and voltage signals, reducing the need for multiple module types.
• High Signal Integrity: Differential input options improve noise resistance and measurement stability.
• Efficient System Design: Combines multiple input modes to simplify panel layout and system architecture.
• Reliable ControlLogix Integration: Designed for stable operation within ControlLogix platforms.
• Industrial-Grade Performance: Suitable for continuous operation in demanding industrial environments.
