Bently Nevada 330162-02-40-40-05-05-94-01-02 Single Triaxial HP Feedthrough for 3300 System
- Product Details
- FAQs
- Related
- Contact Us
- Packing & Delivery
- Product Ratings
Product Introduction
The 330162-02-40-40-05-05-94-01-02 Single Triaxial HP Feedthrough is a specialized signal transmission component designed for high-pressure applications within the 3300 monitoring platform of Bently Nevada. It serves as a sealed electrical interface that allows triaxial proximity probe signals to pass safely through pressure boundaries without compromising system integrity.
In rotating machinery monitoring systems—particularly those installed in turbines, compressors, and pressurized process equipment—maintaining signal integrity while preserving pressure containment is critical. This high-pressure (HP) feedthrough assembly is engineered to ensure reliable transmission of proximity probe signals from inside a pressurized casing to external monitoring instrumentation.
Product Specifications
| Parameter | Specification |
|---|---|
| Product Type | Single Triaxial High-Pressure Feedthrough |
| Model Number | 330162-02-40-40-05-05-94-01-02 |
| System Compatibility | 3300 Monitoring System |
| Cable Type | Triaxial configuration |
| Length Option | 4 meters |
| Pressure Boundary Application | High-pressure sealed interface |
| Signal Type | Eddy current proximity probe signal transmission |
| Sealing Method | Industrial-grade hermetic sealing |
| Mechanical Construction | Heavy-duty industrial design |
| Application Scope | Turbines, compressors, and pressurized machinery |
| Shipping Weight | 3 kg |
Applications
• Steam Turbine Pressure Casings
Provides sealed signal transmission across turbine pressure boundaries.
• Gas Compressor Systems
Ensures safe probe signal routing from high-pressure chambers to monitoring racks.
• Petrochemical Processing Equipment
Maintains containment integrity while transmitting vibration data.
• Power Generation Facilities
Supports shaft vibration monitoring within pressurized turbine housings.
• High-Pressure Industrial Machinery
Used in applications where electrical signals must cross sealed mechanical barriers.
• Condition Monitoring Retrofits
Ideal for upgrading older pressure feedthrough assemblies in 3300 systems.
Advantages
• High-Pressure Sealing Integrity
Maintains reliable containment without signal leakage or environmental intrusion.
• Stable Signal Transmission
Triaxial design minimizes noise and electromagnetic interference.
• Extended 4-Meter Length Option
Provides flexibility for remote monitoring cabinet placement.
• Robust Industrial Construction
Engineered for continuous operation in demanding environments.
• System Compatibility
Designed specifically for seamless integration with 3300 monitoring platforms.
• Improved Operational Safety
Supports safe monitoring without compromising pressure vessel integrity.
FAQ
1. What monitoring system is this feedthrough designed for?
It is specifically designed for integration with the 3300 monitoring system platform.
2. What is the purpose of a high-pressure feedthrough?
It allows electrical signals to pass through a sealed pressure boundary while maintaining containment integrity.
3. Why is a triaxial configuration used in this design?
Triaxial construction enhances signal shielding and reduces electrical noise interference.
4. Is this feedthrough suitable for turbine applications?
Yes, it is commonly used in steam and gas turbine pressure casing installations.
5. Can it be used in compressor monitoring systems?
Yes, it supports signal transmission in high-pressure compressor environments.
6. Does the 4-meter length affect signal quality?
The design ensures stable signal transmission across the specified length without significant degradation.
7. Is it compatible with standard 3300 proximity probes?
Yes, it is engineered for use with compatible 3300 series proximity probe systems.
8. What type of sealing is used in this assembly?
It utilizes industrial-grade hermetic sealing suitable for high-pressure environments.
9. Can it operate in high-temperature areas?
It is designed for industrial environments typically found in turbine and compressor systems.
10. Does installation require special handling?
Installation should follow standard industrial procedures for pressure boundary components to ensure proper sealing and alignment.
Related Models
| Model Number | Description |
|---|---|
| 330130-040-00-00 | 3300 XL Standard Extension Cable |
| 330101-00-40-10-02-00 | 3300 Proximity Probe |
| 330103-00-04-10-02-00 | 3300 8 mm Probe |
| 330180-50-00 | 3300 Proximitor Sensor |
| 330850-50-00 | 3300 Series Interface Module |
| 3300/16 | Dual Vibration Monitor Module |
Popular Models
| Model Number | Product Type |
|---|---|
| 3300/42M | Vibration Monitoring Module |
| 3500/42M | Proximitor/Seismic Monitor Module |
| 3300 XL 8 mm Probe | Eddy Current Proximity Probe |
| 3300 XL Proximitor | Signal Conditioning Unit |
| 7200 5 mm Probe | Proximity Monitoring Probe |
| 3500/22M | Transient Data Interface Module |
