Bently Nevada 330704-000-040-10-02-05 3300 XL 11 mm Proximity Probes

Company Information
E-mail		[email protected]
Mobile		+8613666033393
Whatsapp		+8613666033393
WeChat		13666033393
Add		Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Product Introduction

The Bently Nevada 330704-000-040-10-02-05 3300 XL 11 mm Proximity Probe is a precision-engineered non-contact vibration and displacement sensor designed for advanced condition monitoring and machinery protection. It is part of the world-renowned 3300 XL series developed by Bently Nevada, a leader in machinery diagnostics and asset protection technologies.

This proximity probe operates based on eddy current sensing technology, detecting the distance between the probe tip and a conductive surface such as a rotating shaft. It delivers a voltage output that is directly proportional to the distance between the probe and the target, enabling precise measurement of shaft vibration, displacement, and position.

The 330704-000-040-10-02-05 model combines superior measurement accuracy, wide operating range, and rugged durability, making it suitable for critical rotating equipment such as turbines, compressors, motors, and pumps. Its stainless-steel construction, enhanced electromagnetic shielding, and stable calibration performance make it one of the most reliable sensors for industrial monitoring.

This probe is used in conjunction with Bently Nevada 3300 XL Proximitor Sensors and extension cables to form a complete transducer system compliant with API 670 standards. It ensures consistent and high-quality data collection for vibration analysis and equipment protection in demanding environments.

---

Technical Specifications

---

Applications

The Bently Nevada 330704-000-040-10-02-05 Proximity Probe is specifically designed for rotating machinery monitoring and protection. It provides high-fidelity data on shaft vibration, displacement, and axial position, which are critical parameters in preventing catastrophic mechanical failures.

Its reliability and accuracy make it a preferred choice in various industries where equipment uptime and operational safety are critical.

Key application areas include:

• Steam and Gas Turbines: Monitoring rotor displacement and vibration to detect imbalance, rubs, and thermal bowing.

• Centrifugal Compressors: Detecting rotor instability, bearing wear, and misalignment.

• Motors and Generators: Measuring shaft position and vibration amplitude to assess bearing condition.

• Pumps and Blowers: Monitoring for cavitation, unbalance, and mechanical looseness.

• Gearboxes: Detecting misalignment and gear mesh abnormalities through vibration analysis.

• Industrial Machinery: Integrated into condition monitoring systems for continuous health diagnostics.

The probe’s rugged construction and advanced shielding make it suitable for operation in oil-contaminated, high-temperature, and electrically noisy environments, such as refineries, power plants, and offshore facilities.

---

Product Advantages

The 330704-000-040-10-02-05 3300 XL Proximity Probe combines high performance, exceptional reliability, and long-term operational stability. It is engineered to deliver consistent accuracy and superior resistance to environmental challenges commonly encountered in industrial applications.

Key advantages include:

• High Accuracy and Stability: ±1% linearity over the entire range for precise measurement.

• Durable Construction: Stainless steel housing provides protection from corrosion, oil, and mechanical stress.

• Wide Frequency Response: Measures vibration across a wide frequency spectrum up to 10 kHz.

• Advanced EMI/RFI Shielding: Double-shielded coaxial cable design eliminates electrical noise interference.

• Thermal Resilience: Maintains accuracy across extreme temperature variations.

• API 670 Compliance: Fully meets industry standards for critical machinery protection.

• Oil and Moisture Resistance: Sealed design ensures reliable performance in contaminated environments.

• Maintenance-Free Operation: Non-contact sensing eliminates physical wear or need for recalibration.

• Seamless System Integration: Fully compatible with all Bently Nevada 3300 XL Proximitor Sensors and accessories.

• Proven Field Reliability: Trusted by industries worldwide for decades of stable performance.

---

FAQ

1. What is the working principle of the Bently Nevada 330704-000-040-10-02-05 proximity probe?
   It operates using the eddy current principle, generating an electromagnetic field that interacts with the conductive target surface to measure distance and vibration without physical contact.

2. Which Proximitor Sensor is compatible with this probe?
   It is designed for use with the Bently Nevada 3300 XL Proximitor Sensor, forming a complete calibrated transducer system for accurate displacement measurement.

3. What is the typical sensitivity of this probe system?
   The system provides a 200 mV/mil (7.87 mV/μm) output, ensuring precise detection of shaft movement and vibration amplitude.

4. How does this probe maintain accuracy in varying temperatures?
   It uses temperature-compensated materials and electronic design, allowing stable operation from -35°C to +177°C with minimal drift.

5. What measures protect the probe from electrical interference?
   The probe features a double-shielded coaxial cable, effectively reducing noise from electromagnetic and radio frequency interference.

6. Which target materials are recommended for calibration?
   The probe is factory-calibrated for AISI 4140 steel, and small correction factors may be applied if used with other conductive materials.

7. Can the probe measure both dynamic and static signals?
   Yes, it can monitor shaft vibration (dynamic) and position or thermal growth (static), providing comprehensive condition data.

8. What are key installation considerations for this probe?
   The probe must be mounted perpendicular to the shaft surface, maintaining proper gap spacing and secure cable connections to ensure accurate output.

9. How is the probe output processed within the system?
   The signal is transmitted to the Proximitor Sensor, which converts it into a standard voltage output proportional to the shaft displacement.

10. Does the probe comply with industrial standards?
    Yes, it fully meets API 670 requirements for machinery protection systems and complies with CE and CSA certifications for safety and reliability.

---
