GE Fanuc IC697PCM711 Coprocessor Module
- Product Details
- FAQs
- Related
- Contact Us
- Packing & Delivery
- Product Ratings
Product Overview
The GE Fanuc IC697PCM711 Coprocessor Module is a single-slot programmable coprocessor designed for the Series 90-70 PLC family. It extends system capability by offloading computation, data handling, and serial communications from the main CPU. The module supports user programs (MegaBasic), provides serial connectivity for external devices, and offers expandable memory with battery-backed retention—making it suitable for systems requiring additional processing, data acquisition, or protocol bridging without replacing the primary CPU.
Key Features
-
Single-slot programmable coprocessor for Series 90-70 systems
-
Runs user programs (MegaBasic) to implement custom logic and tasks
-
Two configurable serial ports (RS-232 / RS-422 / RS-485) for external device interfacing
-
Onboard user memory with optional expansion capability
-
Battery-backed CMOS memory for program and data retention
-
Software-configurable (no jumpers or DIP switches) for simplified setup
-
Low backplane current draw and compact rack mounting
-
Front-panel LEDs for status and diagnostics
Technical Specifications
| Item | Details |
|---|---|
| Model | IC697PCM711 |
| Module Type | Programmable Coprocessor Module |
| Supported System | GE Fanuc Series 90-70 PLC |
| Microprocessor | 12 MHz Intel 80C186 |
| User Memory (onboard) | ≈ 95 KB |
| Optional Memory Expansion | Up to 512 KB (via expansion daughter module) |
| Serial Ports | 2 × configurable (RS-232 / RS-422 / RS-485) |
| Backplane Power Requirement | +5 VDC, nominal 1.0 A |
| Battery Backup | Battery-backed CMOS for program/data retention |
| Status Indicators | Front-panel LEDs (status/activity) |
| Slot Requirement | Single rack slot (Series 90-70) |
| Dimensions | 195.5 × 40 × 143 mm |
| Weight | 0.5 kg |
| Operating Temperature | Industrial range (designed for typical PLC enclosure conditions) |
| Mounting | Standard Series 90-70 rack mount |
Industry Applications
-
Offloading intensive computation or I/O handling from the main CPU
-
Data acquisition and local logging within PLC racks
-
Serial gateway or protocol conversion to connect HMIs, barcode readers, scales, or third-party devices
-
Legacy system enhancement where CPU replacement is not practical
-
Localized operator interface tasks and peripheral communications
Frequently Asked Questions (FAQ)
1 .What is the primary function of the IC697PCM711?
It serves as a programmable coprocessor that executes user programs and offloads communication and computation tasks from the main PLC CPU.
2 .Which PLC family is it compatible with?
It is designed for the GE Fanuc Series 90-70 PLC family.
3 .How is the module programmed?
User programs are typically developed in MegaBasic and loaded to the module through the Series 90-70 programming tools.
4 .How many serial ports does it provide and what interfaces do they support?
It provides two serial ports configurable for RS-232, RS-422, or RS-485 to interface with a variety of external devices.
5 .What memory options are available?
The module includes onboard user memory (~95 KB) and supports optional memory expansion up to 512 KB.
6. Does it retain memory when power is removed?
Yes. The module uses battery-backed CMOS memory to retain program and data for extended periods.
7 。Is hardware configuration required (jumpers or switches)?
No. The module is configured via software; no DIP switches or jumpers are required for normal operation.
8. What typical devices can be attached to its serial ports?
Common devices include HMIs, barcode scanners, scales, data loggers, printers, and other serial-enabled field equipment.
Related GE Fanuc Models
| Model | Description |
|---|---|
| IC697CPU772 | Series 90-70 CPU Module |
| IC697PCM711 | Programmable Coprocessor Module |
| IC697MEM713 | Memory Expansion Module |
| IC697CMM742 | Communication Module |
| IC697BEM711 | Bus Receiver Module |
Popular GE Fanuc Models
| Model | Description |
|---|---|
| IC697CPU772 | Series 90-70 CPU Module |
| IC697ALG230 | Analog Input Module |
| IC697ALG321 | Analog Input Module |
| IC697MDL340 | 32-Point Discrete Input Module |
| IC697MDL654 | 32-Point Discrete Output Module |
| IC697PCM711 | Programmable Coprocessor Module |
Frequently Asked Questions (FAQ)
1 .What is the primary function of the IC697PCM711?
It serves as a programmable coprocessor that executes user programs and offloads communication and computation tasks from the main PLC CPU.
2 .Which PLC family is it compatible with?
It is designed for the GE Fanuc Series 90-70 PLC family.
3 .How is the module programmed?
User programs are typically developed in MegaBasic and loaded to the module through the Series 90-70 programming tools.
4 .How many serial ports does it provide and what interfaces do they support?
It provides two serial ports configurable for RS-232, RS-422, or RS-485 to interface with a variety of external devices.
5 .What memory options are available?
The module includes onboard user memory (~95 KB) and supports optional memory expansion up to 512 KB.
6. Does it retain memory when power is removed?
Yes. The module uses battery-backed CMOS memory to retain program and data for extended periods.
7 。Is hardware configuration required (jumpers or switches)?
No. The module is configured via software; no DIP switches or jumpers are required for normal operation.
8. What typical devices can be attached to its serial ports?
Common devices include HMIs, barcode scanners, scales, data loggers, printers, and other serial-enabled field equipment.
Related GE Fanuc Models
| Model | Description |
|---|---|
| IC697CPU772 | Series 90-70 CPU Module |
| IC697PCM711 | Programmable Coprocessor Module |
| IC697MEM713 | Memory Expansion Module |
| IC697CMM742 | Communication Module |
| IC697BEM711 | Bus Receiver Module |
Popular GE Fanuc Models
| Model | Description |
|---|---|
| IC697CPU772 | Series 90-70 CPU Module |
| IC697ALG230 | Analog Input Module |
| IC697ALG321 | Analog Input Module |
| IC697MDL340 | 32-Point Discrete Input Module |
| IC697MDL654 | 32-Point Discrete Output Module |
| IC697PCM711 | Programmable Coprocessor Module |
