Honeywell FC-CPCHAS-0001 Chassis for Control Processor

Product Introduction

The Honeywell FC-CPCHAS-0001 is a highly reliable and rugged chassis designed for use with Honeywell’s Control Processors in critical industrial automation environments. It provides the necessary support and protection for Honeywell’s control processors, ensuring seamless integration and enhanced operational efficiency in a variety of industrial settings. The chassis serves as the backbone for control system setups, offering essential power, cooling, and system connectivity to support high-performance operations.

Honeywell’s FC-CPCHAS-0001 is part of the company’s broader suite of process control and automation products, offering scalability and modularity to meet diverse system requirements. The chassis is engineered to support a variety of control modules, offering both flexibility and robustness to handle the demands of complex industrial control systems, from power generation and oil and gas to manufacturing and chemical processing.

---

Technical Specifications

Parameter	Value
Product Type	Control Processor Chassis
Model Number	FC-CPCHAS-0001
Mounting Style	Rack Mount
System Capacity	Supports up to 12 Control Modules
Power Supply	24V DC
Cooling Method	Active Cooling with Fans
Enclosure Rating	NEMA 1, IP20
Dimensions (HxWxD)	35 x 225 x 175 mm
Weight	0.66 kg
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5% to 95% non-condensing
Warranty	1 year
Certifications	CE, UL, CSA, RoHS
Max. Control Modules	12 (Depending on Module Configuration)
Communication Ports	Ethernet, Serial, I/O Ports



---

Applications

The Honeywell FC-CPCHAS-0001 Chassis is used across various industrial sectors, including:

• Process Control Systems: For power generation, oil and gas, chemical plants, and refineries.

• Manufacturing Automation: Integration into assembly lines, robotics, and production process monitoring.

• Building Management Systems (BMS): Used in large-scale facilities such as commercial buildings, airports, and hospitals.

• Energy Management Systems (EMS): Ensures control over energy distribution and monitoring in smart grid applications.

• Water Treatment Plants: For controlling pumps, filtration systems, and monitoring water quality.

• Industrial Equipment Monitoring: Integration into systems that require continuous monitoring and real-time data collection.

---

Product Advantages

• Scalability and Flexibility: The FC-CPCHAS-0001 chassis can support a variety of Honeywell control processors and I/O modules, making it highly flexible and scalable for various industrial applications.

• Robust Design: With a NEMA 1 enclosure rating, this chassis is built to withstand demanding environments, offering both physical and electrical protection.

• Reliable Cooling: Equipped with active cooling fans, it ensures optimal temperature regulation, maintaining the reliability and efficiency of the control system.

• Modular Architecture: The chassis can accommodate up to 12 control modules, offering enhanced customization for complex control systems.

• Easy Integration: Seamlessly integrates with Honeywell’s Process Control System platforms and allows for easy installation and expansion.

• Space-Efficient: Its compact dimensions (490 x 447 x 178 mm) allow it to be easily integrated into existing rack-mounted configurations, saving valuable space.

• Long-Lasting Performance: Honeywell’s rigorous testing ensures high durability and long operational life, reducing the need for frequent replacements.

• Global Compliance: Certified to meet international standards such as UL, CE, and RoHS, ensuring safety, quality, and environmental responsibility.

---

Recent News Headlines

1. Honeywell Expands Control System Solutions with New Chassis Models for Industrial Automation

2. Honeywell Introduces Advanced Cooling Technology for Process Control Chassis

3. Honeywell’s FC-CPCHAS-0001 Powers Up New Control Systems in Power Generation Sector

4. Honeywell Launches Scalable and Flexible Chassis for Modular Control Applications

5. Global Refineries Integrate Honeywell Control Processors with FC-CPCHAS-0001 for Enhanced Operations

---

FAQs (Frequently Asked Questions)

1. What is the primary function of the Honeywell FC-CPCHAS-0001 chassis?
   The chassis provides the structural and electrical support for Honeywell’s control processors, ensuring the system operates effectively by managing power, cooling, and communication.

2. What control modules can be used with the FC-CPCHAS-0001 chassis?
   It supports Honeywell’s range of control processors and I/O modules, offering flexibility to integrate various configurations based on system needs.

3. How many control modules can the chassis accommodate?
   The chassis can support up to 12 control modules, depending on your system configuration.

4. What is the operating temperature range for the FC-CPCHAS-0001 chassis?
   The operating temperature range is 0°C to 50°C (32°F to 122°F).

5. Is the chassis suitable for outdoor use?
   No, the chassis has an IP20 rating and is designed for indoor use in environments that do not expose it to direct weather conditions.

6. What type of cooling does the chassis use?
   It uses active cooling with fans to ensure the proper temperature range is maintained within the chassis for optimal performance.

7. Can the FC-CPCHAS-0001 chassis be mounted in a standard 19-inch rack?
   Yes, the chassis is designed for rack-mounted installation and fits into a standard 19-inch rack.

8. What are the certifications of the FC-CPCHAS-0001 chassis?
   It is CE, UL, CSA, and RoHS certified, ensuring compliance with global safety and environmental standards.

9. Is the chassis compatible with older Honeywell control processors?
   Yes, the chassis is backward compatible with several older Honeywell control processors, providing flexibility in system upgrades.

10. What is the warranty on the Honeywell FC-CPCHAS-0001 chassis?
    We provide one year warranty.

---
