Honeywell MU-TAIH03 51309136-125 High Level Analog Input Module
- Product Details
- FAQs
- Related
- Contact Us
- Packing & Delivery
- Product Ratings
Product Overview
The Honeywell MU-TAIH03 51309136-125 is a high-level analog input module designed for use within the High-Performance Process Manager (HPM) architecture. It enables precise acquisition of analog process signals and supports single-ended or differential inputs. This module is essential for interfacing analog field devices such as pressure, flow, and temperature transmitters within Honeywell’s TPS (TotalPlant Solution) systems.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | MU-TAIH03 |
| Part Number | 51309136-125 |
| Input Type | High-Level Analog Inputs (HLAI) |
| Signal Range | 0–5 VDC / 4–20 mA configurable |
| Input Channels | 8 (differential or single-ended) |
| Isolation | Channel-to-channel and channel-to-ground |
| Signal Conditioning | Integrated |
| Interface | Connects to IOP via FTA |
| Mounting | Field Termination Assembly (FTA) |
| Dimensions (W×H×D) | 26 × 242 × 175 mm |
| Weight | 0.2 kg |
| Operating Temperature | 0°C to 60°C |
| Compliance | CE Certified |
Applications
-
Chemical and petrochemical plants
-
Oil & gas upstream/downstream instrumentation
-
Power generation process control
-
Water treatment and distribution systems
-
Pulp and paper manufacturing
-
Pharmaceutical production environments
Product Advantages
-
Supports both single-ended and differential input configurations
-
High noise immunity and input isolation for robust signal integrity
-
Seamless integration with HPM subsystems and FTAs
-
CE compliance ensures suitability for regulated industrial environments
-
Supports redundancy configurations for increased system reliability
Frequently Asked Questions (FAQ)
Q1: What type of signals does the MU-TAIH03 support?
A1: It supports high-level analog signals, including 0–5 VDC and 4–20 mA.
Q2: How many input channels are available?
A2: The module supports up to 8 input channels.
Q3: Can the module be configured for differential inputs?
A3: Yes, it supports both single-ended and differential input configurations.
Q4: Is the MU-TAIH03 compatible with redundant IOP setups?
A4: Yes, it supports redundancy for high-availability systems.
Q5: What kind of field devices can be connected?
A5: It is commonly used with transmitters for pressure, temperature, flow, and level.
Q6: What is the standard operating temperature range?
A6: The module operates between 0°C and 60°C.
Q7: Does the MU-TAIH03 include isolation features?
A7: Yes, it provides channel-to-channel and channel-to-ground isolation.
Q8: How is the module integrated into the system?
A8: It connects through a dedicated Field Termination Assembly (FTA) and communicates with the Input/Output Processor (IOP).
Q9: Is this module CE certified?
A9: Yes, the MU-TAIH03 is CE compliant.
Q10: What kind of maintenance is required?
A10: The module is designed for minimal maintenance; periodic inspection of wiring and status LEDs is recommended.
Related or Similar Honeywell Models
