Schneider VW3A1112 Door Mounting Kit

Product Introduction

The Schneider Electric VW3A1112 Door Mounting Kit is a dedicated installation accessory designed for Altivar series variable speed drives, specifically for mounting graphic display terminals on enclosure doors. This kit enables operators to relocate the terminal interface to the cabinet front, improving accessibility, safety, and operational efficiency.

Engineered to maintain a high protection level, the VW3A1112 is suitable for installation on cabinet doors with IP65 / UL Type 12 protection requirements. It ensures that the graphic terminal remains fully protected against dust, moisture, and industrial contaminants even when mounted remotely.

The kit is supplied as a complete solution, including all mechanical, sealing, grounding, and communication components required for installation. By providing a reliable and standardized mounting method, the VW3A1112 simplifies system integration and supports professional-grade panel design in industrial automation environments.

---

Product Specifications

---

Applications

• Remote mounting of graphic terminals, enabling front-door operation

• Altivar drive control cabinets, improving ergonomics and accessibility

• Industrial automation panels, requiring sealed operator interfaces

• Harsh industrial environments, where IP65 protection is mandatory

• Machine and process control systems, supporting safe operator interaction

• Commissioning and maintenance setups, reducing cabinet access frequency

---

Advantages

• Maintains IP65 / UL Type 12 protection, even when terminals are door-mounted

• Complete installation kit, eliminating the need for additional accessories

• Optimized for Altivar graphic terminals, ensuring mechanical compatibility

• Integrated sealing and grounding, enhancing safety and reliability

• Long RJ45 connection capability, supporting flexible cabinet layouts

• Professional panel finish, improving overall system appearance

• Simplified installation process, reducing setup time and errors

FAQ

1. What is the purpose of the VW3A1112 door mounting kit?
   It is used to mount Altivar graphic display terminals on enclosure doors while maintaining protection levels.

2. Which protection rating does the kit support?
   It is designed for IP65 and UL Type 12 cabinet door installations.

3. Is this kit compatible with Altivar graphic terminals?
   Yes, it is specifically intended for use with Altivar graphic display terminals.

4. Does the kit include communication components?
   Yes, it includes an RJ45 connector and an RJ45 installation cable.

5. Can the terminal remain protected when not connected?
   Yes, a dedicated cover plate maintains IP65 protection when terminals are disconnected.

6. Is grounding supported in this mounting kit?
   Yes, the kit includes grounding components to ensure electrical safety.

7. Is the mounting hardware included?
   Yes, all fixing nuts, anti-rotation pins, and mounting elements are supplied.

8. Is special tooling required for installation?
   No, a dedicated tightening tool is included in the kit.

9. Can this kit be used in industrial environments?
   Yes, it is designed for industrial control cabinets and automation systems.

10. Does it improve operator safety?
    Yes, by allowing front-door terminal access, it reduces the need to open energized cabinets.
