Yokogawa EC401-51 S3 ESB Bus Coupler Module
- Product Details
- FAQs
- Related
- Contact Us
- Packing & Delivery
- Product Ratings
Product Introduction
The Yokogawa EC401-51 S3 ESB Bus Coupler Module is a critical interface component for connecting Field Control Units (FCUs) to the Enhanced System Bus (ESB) in distributed control systems. This module acts as a bridge between ESB field devices and the main control network, providing high-speed, reliable communication for process automation and control.
Designed for mission-critical industrial applications, the EC401-51 S3 supports dual-redundant configurations, ensuring uninterrupted data flow even in the event of a communication channel failure. It features advanced diagnostics, error detection, and LED indicators for real-time status monitoring. Its compact modular design allows easy integration into existing Yokogawa systems, making it suitable for industries such as oil & gas, chemical, petrochemical, and power generation.
Product Specifications
| Parameter | Description |
|---|---|
| Model | EC401-51 S3 |
| Function | ESB Bus Coupler Module |
| Communication Protocol | ESB (Enhanced System Bus) |
| Data Transmission Speed | High-speed synchronous communication |
| Number of Connectable Units | Up to 9 units |
| Power Supply | 24 V DC (nominal) |
| Current Consumption | Approx. 0.5 A |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -20°C to +70°C |
| Relative Humidity | 5% to 95% RH (non-condensing) |
| Installation Method | Rack-mounted in FCU |
| Redundancy Support | Dual-redundant communication paths |
| Diagnostic Features | Self-diagnostics, Error Logging, LED Status |
| Firmware Update | Supported (online upgrade) |
| Compliance | CE, RoHS |
| Dimensions (H × W × D) | 130 x 129.5 x 32.8 mm |
| Weight | 0.24 kg |
Applications
-
Distributed Control Systems (DCS): Connects FCUs to Node Units and field devices for reliable communication.
-
Process Automation: Supports continuous data exchange for automated control processes.
-
Redundant Industrial Systems: Maintains operation in safety-critical environments.
-
Power Generation: Enables stable monitoring and control in power plants.
-
Oil & Gas Industry: Ensures accurate and stable communication for upstream, midstream, and downstream operations.
-
Chemical & Petrochemical Plants: Supports complex process control and hazardous area communication.
Product Advantages
-
High-Speed Communication: Ensures rapid and reliable data transfer across ESB networks.
-
Dual-Redundancy Support: Maintains uninterrupted communication even if one path fails.
-
Compact, Modular Design: Simplifies installation and integration into existing racks.
-
Advanced Diagnostics: Self-diagnostics, error logging, and LED indicators facilitate proactive maintenance.
-
Wide Compatibility: Works with various Yokogawa FCUs and Node Units.
-
Certified Compliance: CE and RoHS approved for safety and environmental standards.
