Yokogawa EC402-50 ESB Bus Coupler Module

Product Introduction

The Yokogawa EC402-50 ESB Bus Coupler Module is a crucial component of Yokogawa’s advanced industrial automation systems. It serves as an interface between different systems, connecting the I/O modules to a control system for seamless communication. The EC402-50 ESB Bus Coupler Module is specifically designed for integration into Yokogawa’s CENTUM VP control systems, facilitating a stable and efficient data exchange between field devices and the central processing units (CPUs). With its high reliability and robust design, the EC402-50 ensures that industrial processes can be monitored and controlled effectively in various sectors such as chemical, power, and oil & gas industries.

---

Product Specifications

Below are the detailed technical specifications of the Yokogawa EC402-50 ESB Bus Coupler Module:

Specification	Value
Module Type	Bus Coupler Module
Supported Bus System	ESB (Ethernet Switch Bus)
Input/Output Channels	32 I/O channels
Operating Voltage	24 V DC
Communication Protocol	Ethernet, Modbus, Profibus
Dimensions	130 x 129.5 x 32.8 mm
Weight	0.24 kg
Operating Temperature Range	-20°C to 60°C
Humidity Range	5% to 95% (non-condensing)
Power Consumption	4W
Mounting Type	DIN rail mount
Status Indication	LED indicators
Environmental Protection	IP20
Certifications	UL, CE, ATEX



---

Product Applications

The Yokogawa EC402-50 ESB Bus Coupler Module is designed for use in a wide variety of industrial applications where stable and reliable communication between field devices and control systems is essential. Its main applications include:

• Process Automation: Used extensively in chemical, petrochemical, and pharmaceutical plants for connecting field devices to the control system.

• Power Plants: Helps facilitate the connection between various monitoring and control devices to ensure smooth and efficient operations.

• Oil & Gas: Plays a critical role in ensuring real-time communication between sensors, actuators, and the control system in harsh environments.

• Water Treatment: Used for connecting sensors and actuators in municipal and industrial water treatment facilities.

• Manufacturing: Integrates with factory automation systems to monitor machinery and production processes in real time.

---

Product Advantages

1. Reliable Communication: The EC402-50 ensures seamless communication between the field devices and control systems, reducing the risk of data loss or miscommunication.

2. High Scalability: It supports a wide range of I/O modules and communication protocols, making it suitable for a variety of applications.

3. Rugged Design: The module is designed to withstand harsh industrial environments, with an operating temperature range of -20°C to 60°C and protection against dust and water (IP20).

4. Compact Size: The small footprint of the EC402-50 allows for easy installation in tight spaces, saving valuable rack space.

5. Easy Integration: With support for standard communication protocols like Ethernet, Modbus, and Profibus, the module integrates easily into existing control systems.

6. Cost-Effective: The EC402-50 offers reliable performance at a cost-effective price, making it an excellent choice for projects with budget constraints.

7. LED Status Indicators: Clear LED indicators make it easy to monitor the status of the module, ensuring quick identification of issues.

8. Global Certifications: The module is certified with UL, CE, and ATEX approvals, ensuring it meets the stringent standards required for operation in hazardous environments.

---
