Product Introduction
The Yokogawa F3YD32-1H is a high-speed output module designed for the FA-M3 series programmable logic controllers (PLCs). It provides reliable and fast digital output capabilities suitable for applications requiring rapid signal switching and precise timing control. With advanced response time and robust build quality, this module supports real-time control in complex automation environments. Its compact design allows seamless integration into control cabinets while ensuring durability and stability under demanding industrial conditions.
Product Parameters
| Parameter | Specification |
|---|---|
| Model Number | F3YD32-1H |
| Product Type | High-Speed Output Module |
| Number of Output Channels | 32 points |
| Output Type | Transistor (High-Speed Switching) |
| Rated Output Voltage | 24 VDC (typical) |
| Output Current per Channel | 0.5 A max. |
| Response Time | Less than 0.1 ms |
| Isolation | Optical isolation between I/O and internal bus |
| Power Consumption | 7 W |
| Operating Temperature | 0 to 55°C |
| Storage Temperature | -20 to 75°C |
| Dimensions | 84.5 x 102 x 28.9mm |
| Weight | 0.11 kg |
Product Applications
-
Packaging machinery with fast cycle times.
-
Motion control for robotics and servo-driven equipment.
-
Semiconductor and electronic manufacturing systems.
-
Automotive assembly lines requiring synchronized outputs.
-
Process automation for material handling systems.
-
High-performance test benches and measurement systems.
Product Advantages
-
High-Speed Switching: Provides sub-millisecond response for time-critical operations.
-
Compact Design: Saves panel space and simplifies installation in dense automation environments.
-
Optical Isolation: Enhances system reliability and protects against signal interference.
-
High Channel Density: Supports 32 high-speed outputs in a single module, increasing efficiency.
-
Stable Performance: Designed for continuous operation in harsh industrial conditions.
-
Scalability: Easily integrates with other FA-M3 PLC modules for extended control systems.
FAQ
Q1: What type of output does the F3YD32-1H support?
A1: The module supports transistor-type outputs optimized for high-speed switching.
Q2: Can this module handle simultaneous switching of all 32 channels?
A2: Yes, it can switch all channels simultaneously within its rated current capacity.
Q3: What is the isolation method used in this module?
A3: It uses optical isolation between the I/O channels and the internal system bus.
Q4: What is the typical response time for each channel?
A4: The response time is less than 0.1 milliseconds.
Q5: Is the module suitable for use in motion control applications?
A5: Yes, it is well-suited for motion control where rapid and accurate output is required.
Q6: What is the maximum current output per channel?
A6: Each channel supports up to 0.5 A maximum load.
Q7: Does the module support diagnostic functions for outputs?
A7: Yes, it includes error detection features to identify abnormal conditions.
Q8: Can the module be used in redundant configurations?
A8: Yes, it can be applied in redundancy setups when paired with supported FA-M3 systems.
Q9: What protection features are included in the outputs?
A9: The module includes overcurrent protection and short-circuit protection for safety.
Q10: Is there any restriction on wiring length for high-speed signals?
A10: Yes, to maintain high-speed performance, wiring should follow Yokogawa’s recommended maximum cable length guidelines.
