ABB PP875H 3BSE092983R1 Touch Screen Panel

Product Introduction

The ABB PP875H 3BSE092983R1 Touch Screen Panel is a high-brightness industrial Human Machine Interface (HMI) designed for demanding automation applications where superior display visibility is required. As part of the ABB Panel 800 series, it provides operators with an intuitive touchscreen interface for machine control, process monitoring, alarm management, and system diagnostics.

Featuring a 7-inch touchscreen display with an exceptional brightness of 1000 cd/m², the PP875H offers excellent readability in bright industrial environments. Powered by a 1 GHz ARM9 processor and equipped with 2 GB of memory, the panel delivers responsive performance for advanced visualization applications. Its compact design and wide operating temperature range make it suitable for both indoor and challenging industrial installations.

The PP875H is widely used in manufacturing, power generation, water treatment, transportation, mining, and infrastructure automation systems.

---

Product Specifications

---

Applications

• Industrial Automation Systems – Provides real-time machine monitoring and control.

• Outdoor Control Installations – High brightness display improves visibility in bright environments.

• Power Generation Facilities – Displays process information and operating parameters.

• Water & Wastewater Treatment Plants – Supports monitoring and control of treatment processes.

• Manufacturing Facilities – Enables efficient operator interaction with production equipment.

• Mining Operations – Provides reliable visualization in demanding environments.

• Transportation Systems – Supports monitoring and control applications.

• Infrastructure Projects – Integrates with building and utility automation systems.

• Packaging Machinery – Provides user-friendly machine operation interfaces.

• Process Industries – Supports alarm management, diagnostics, and trend monitoring.

---

Advantages

• 1000 cd/m² High-Brightness Display – Excellent visibility in brightly lit environments.

• 7-Inch Touchscreen Interface – Provides intuitive and efficient operation.

• 800 × 480 Resolution – Delivers clear process graphics and operational data.

• 1 GHz ARM9 Processor – Ensures responsive application performance.

• 2 GB Main Memory – Supports advanced HMI projects and applications.

• SD Card Expansion Support – Allows convenient data storage and application management.

• Wide Operating Temperature Range – Operates reliably from -10°C to +60°C.

• 24 V DC Power Input – Compatible with standard industrial power systems.

• Compact Design – Fits easily into machine panels and control cabinets.

• Industrial-Grade Reliability – Designed for continuous operation in demanding environments.

FAQ

1. What is the main function of the PP875H panel?
   It serves as a touchscreen human-machine interface for industrial monitoring and control applications.
2. What makes the PP875H different from standard PP875 models?
   Its 1000 cd/m² high-brightness display provides superior visibility in bright environments.
3. What display size does the panel feature?
   The PP875H is equipped with a 7-inch touchscreen display.
4. What is the display resolution?
   The display resolution is 800 × 480 pixels.
5. Which processor powers the panel?
   It uses a 1 GHz ARM9 processor.
6. How much memory is installed?
   The panel includes 2 GB of main memory.
7. Does the panel support removable storage?
   Yes. It features an SD card slot and supports SDHC cards with the appropriate system image.
8. What voltage is required for operation?
   The unit operates from 24 V DC with an allowable range of 18 to 32 V DC.
9. What temperature range can the panel withstand?
   It operates in temperatures from -10°C to +60°C.
10. What is a key advantage of the PP875H?
    Its high-brightness display and industrial-grade design make it ideal for applications requiring excellent screen visibility.
