Allen Bradley 1746-OA8/A SLC 500 AC Digital Input Module

Product Introduction

The Allen-Bradley 1746-OA8/A is an AC digital output module designed for the SLC 500 programmable controller platform. As a Series A module, it provides reliable switching of AC loads in industrial control systems, enabling direct control of field devices operating at standard AC voltage levels.

This module offers 8 general-purpose output channels, each capable of sourcing current to drive loads within the 85–265V AC range. It is commonly used to control devices such as contactors, solenoids, indicator lamps, and other AC-powered equipment. The module converts digital output commands from the PLC into electrical switching actions, allowing precise control over field operations.

Designed for seamless integration into SLC 500 chassis systems, the 1746-OA8/A combines a compact form factor with dependable electrical performance. Its robust construction and stable output characteristics make it suitable for continuous operation in demanding industrial environments.

---

Product Specifications

---

Applications

● Industrial Load Control
Used to control AC-powered devices such as contactors, relays, and indicator lamps in control panels.

● Automation Systems
Provides output control for automated production lines, enabling switching of actuators and auxiliary equipment.

● Material Handling Equipment
Controls conveyors, sorting systems, and signaling devices operating on AC voltage.

● Process Control Applications
Used in industries such as chemical and power systems where AC outputs are required for field control.

● Legacy SLC 500 Installations
Ideal for maintaining and expanding existing SLC 500 systems without major redesign.

---

Advantages

● Wide AC Voltage Compatibility
Supports a broad voltage range (85–265V AC), making it adaptable to various industrial standards.

● Reliable Current Sourcing Output
Ensures stable and consistent operation when driving AC loads.

● Robust Electrical Isolation
Provides protection between field devices and the PLC backplane.

● Compact Modular Design
Easily integrates into SLC 500 chassis, reducing installation complexity.

● Low Maintenance Operation
Solid-state output design reduces mechanical wear compared to relay-based modules.

● Proven Industrial Reliability
Widely used in industrial environments with consistent long-term performance.

FAQ

1. What type of loads can the 1746-OA8/A control?
   The module is designed to control AC loads such as contactors, solenoids, indicator lamps, and other devices operating within the 85–265V AC range.
2. What does current sourcing mean in this module?
   Current sourcing means the module provides voltage to the load when the output is activated, allowing current to flow from the module to the field device.
3. Is the output type mechanical or solid-state?
   The module uses solid-state triac outputs, which provide fast switching and longer service life compared to mechanical relays.
4. Can this module be used with DC loads?
   No, it is specifically designed for AC loads. Using it with DC loads may result in improper operation or failure to switch correctly.
5. What is the effect of leakage current in the off state?
   A small leakage current may flow even when the output is off, which could cause very sensitive loads (such as small LEDs) to remain slightly energized.
6. Does the module provide channel isolation?
   The outputs are grouped, and while there is isolation between the field side and the backplane, individual channel isolation is not provided.
7. How does the module handle voltage surges?
   It includes internal protection components to help withstand transient voltage spikes commonly found in industrial environments.
8. Is it suitable for high-speed switching applications?
   It can handle standard industrial switching speeds but is not intended for high-frequency switching applications.
9. What wiring precautions should be taken?
   Proper AC wiring practices should be followed, including correct voltage rating, secure connections, and separation from low-level signal wiring.
10. Can the module be used in mixed-voltage systems?
    Yes, as long as each output channel operates within the specified AC voltage range and proper system design is maintained.

Related Models

---

Popular Models
