Allen Bradley 1756-OB16IS ControlLogix DC Isolated Output Module
- Product Details
- FAQs
- Related
- Contact Us
- Packing & Delivery
- Product Ratings
Product Introduction
The Allen-Bradley 1756-OB16IS is a ControlLogix DC isolated digital output module designed for applications that require electrical isolation, flexible sink/source operation, and reliable DC switching within industrial automation systems. As part of the ControlLogix I/O family, this module integrates directly into ControlLogix chassis-based architectures, supporting consistent control behavior and dependable system performance.
The 1756-OB16IS is typically used in environments where field-side electrical conditions differ from controller ground references. Its isolated output design helps protect control electronics from noise, transients, and ground potential differences, making it a practical choice for complex control panels and distributed industrial systems.
Product Specifications
| Parameter | Description |
|---|---|
| Product Type | ControlLogix DC Isolated Output Module |
| Output Type | Isolated DC Digital Output |
| Number of Outputs | 16 channels |
| Output Configuration | Current sinking / sourcing |
| Rated Output Voltage | 12 / 24 VDC |
| Signal Switching | Electronic DC switching |
| Isolation Design | Channel isolation for field protection |
| Chassis Compatibility | ControlLogix chassis |
| Control Platform | ControlLogix automation system |
| System Integration | Backplane-based communication |
| Industrial Rating | Designed for industrial control environments |
| Dimensions | 144.5 × 34.6 × 130.18 mm |
| Weight | 0.181 kg |
Applications
• Used for isolated control of DC actuators, including solenoid valves, relays, and interface devices
• Suitable for automation systems with mixed grounding schemes requiring electrical separation
• Applied in process control and manufacturing systems exposed to electrical noise or transient conditions
• Commonly installed in material handling, packaging, and assembly lines
• Ideal for applications that require flexible sink/source wiring for different field devices
Advantages
• Isolated output architecture enhances protection of the controller and backplane electronics
• Sink/source capability provides flexible wiring options for a wide range of DC field devices
• 16-channel density supports compact system design and efficient chassis utilization
• Standard 12/24 VDC compatibility simplifies integration with common industrial power supplies
• Reliable DC switching performance ensures consistent control behavior
• Designed for stable operation in electrically demanding industrial environments
FAQ
-
What is the primary function of isolation in the 1756-OB16IS?
Isolation helps prevent field-side electrical disturbances from affecting the controller and backplane, improving system reliability. -
How does sink/source output support different wiring requirements?
It allows the module to operate with either sinking or sourcing field devices, increasing wiring flexibility. -
Can the module be used in systems with multiple ground references?
Yes, the isolated design makes it suitable for systems where ground potential differences may exist. -
Is the 1756-OB16IS appropriate for controlling inductive DC loads?
It can control inductive loads such as relays and solenoids when standard suppression practices are applied. -
How is output status communicated to the controller?
Output states are transmitted through the ControlLogix backplane for real-time monitoring and diagnostics. -
Does isolation affect switching performance?
Isolation does not significantly impact switching performance for typical industrial DC output applications. -
Can isolated and non-isolated output modules be used together?
Yes, both types of modules can coexist within the same ControlLogix chassis when properly configured. -
What considerations are important for wiring isolated outputs?
Maintaining separation of field wiring and following grounding best practices are essential for optimal performance. -
How does the module handle electrical noise in industrial installations?
The isolation barrier and internal circuitry help reduce the impact of noise and voltage transients. -
Is the module suitable for centralized ControlLogix architectures?
Yes, it is well suited for centralized systems where multiple DC outputs are managed from a single ControlLogix chassis.
