Allen Bradley 1762-OB16 MicroLogix 16 Point Solid State DC Source Output Module
- Product Details
- FAQs
- Related
- Contact Us
- Packing & Delivery
- Product Ratings
Product Introduction
The Allen-Bradley 1762-OB16 is a MicroLogix expansion module designed to provide reliable and efficient digital output control for MicroLogix 1200 and 1400 systems. As a 16-point solid-state DC output module, it enables precise and fast switching of field devices in a wide range of industrial automation applications.
This module operates with 24 VDC sourcing outputs, making it suitable for driving DC loads such as relays, solenoids, and indicator lights. Its solid-state (transistor) design ensures high-speed operation, long service life, and improved reliability compared to traditional relay-based outputs.
With a compact form factor and DIN rail mounting capability, the 1762-OB16 integrates easily into control panels where space efficiency is critical. The screw terminal connections provide secure and stable wiring, ensuring dependable performance in industrial environments.
Product Specifications
| Parameter | Description |
|---|---|
| Product Name | 1762-OB16 Digital Output Module |
| Brand | Allen-Bradley |
| Series | MicroLogix Expansion Module |
| Module Type | Digital Output (Solid State) |
| Number of Outputs | 16 Points |
| Output Type | DC Source (Transistor) |
| Rated Voltage | 24 VDC |
| Connection Type | Screw Terminal |
| Mounting | DIN Rail |
| Dimensions | 90 × 40.4 × 87 mm |
| Weight | 0.235 kg |
Applications
• Industrial automation systems – Expands output capacity for controlling actuators, relays, and indicator devices.
• Machine control – Widely used in packaging machines, conveyors, and assembly equipment.
• Process control – Suitable for switching valves, alarms, and signaling systems.
• OEM equipment integration – Provides scalable output solutions for compact machines.
• Material handling systems – Ideal for sorting and automated handling applications.
Advantages
• High-speed solid-state outputs – Ensures fast and precise switching performance.
• Long service life – No mechanical wear, reducing maintenance requirements.
• Compact design – Saves panel space and simplifies installation.
• Flexible expansion capability – Easily integrates with MicroLogix systems.
• Reliable wiring connection – Screw terminals ensure stable operation.
• Optimized for DC loads – Designed specifically for 24 VDC industrial applications.
FAQ
- Is the 1762-OB16 a relay output module?
It is a solid-state (transistor) module, not a relay type, which allows faster switching and longer operational life. - What types of devices can be connected to this module?
It is typically used to drive 24 VDC loads such as solenoids, interposing relays, and indicator lights in control systems. - How many outputs does the module provide?
The module includes 16 independent digital output channels for flexible control. - Can it be used with MicroLogix 1400 controllers?
Yes, it is fully compatible with both MicroLogix 1200 and 1400 PLC platforms. - What is the main benefit of transistor outputs?
They provide faster response times and higher reliability compared to mechanical relay outputs. - How is the module installed?
It is mounted on a standard DIN rail, making installation quick and convenient. - What type of wiring connection is used?
The module uses screw terminal connections for secure and stable field wiring. - Is it suitable for high-speed applications?
Yes, its solid-state design makes it ideal for applications requiring frequent or rapid switching. - Can this module expand an existing system?
It is specifically designed as an expansion module to increase output capacity in MicroLogix systems. - In which industries is it commonly used?
It is widely used in manufacturing, packaging, material handling, and general automation systems.
Related Models
| Model | Description |
|---|---|
| 1762-OB8 | 8-point DC output module |
| 1762-OW8 | 8-point relay output module |
| 1762-OW16 | 16-point relay output module |
| 1762-IB16 | 16-point DC input module |
| 1762-IF4 | Analog input module |
| 1762-OF4 | Analog output module |
Popular Models
| Model | Description |
|---|---|
| 1766-L32BXB | MicroLogix 1400 controller |
| 1766-L32AWA | MicroLogix 1400 AC controller |
| 1769-L24ER-QBFC1B | CompactLogix controller |
| 1756-L81E | ControlLogix controller |
| 1756-EN2T | Ethernet module |
| 1756-IB16 | Digital input module |
