The Allen-Bradley 1783-BMS20CGP Stratix 5700 Ethernet Managed Switch is an industrial managed Ethernet switch designed to provide secure, reliable, and high-performance network connectivity for industrial automation systems. As part of the Stratix 5700 series, it combines the familiarity of enterprise networking technologies with features optimized for industrial environments.
The switch offers 16 Fast Ethernet copper ports and 2 Gigabit combo ports that support either copper or SFP fiber connections, enabling flexible network architectures. With support for CIP Sync and advanced management capabilities, the 1783-BMS20CGP helps ensure precise time synchronization, efficient data communication, and improved network performance across automation systems.
This managed switch is widely used in manufacturing plants, process industries, power generation facilities, transportation systems, and industrial infrastructure applications where dependable network communication is essential.
Product Specifications
| Parameter | Description |
|---|---|
| Model | 1783-BMS20CGP |
| Product Type | Managed Ethernet Switch |
| Series | Stratix 5700 |
| Copper Ports | 16 × 10/100 Mbps RJ45 Ports |
| Combo Ports | 2 × 10/100/1000 Mbps Copper/SFP Combo Ports |
| SFP Support | Yes |
| Network Management | Managed Switch |
| Time Synchronization | CIP Sync |
| Power Supply Voltage | 24/48V DC |
| Input Voltage Range | 12V DC to 60V DC |
| Power Connectors | 2 Redundant Power Inputs |
| Software Package | Full Software Feature Set |
| Mounting Type | DIN Rail / Panel Mount |
| Dimensions | 135.8 × 127 × 129.5 mm |
| Weight | 2.04 kg |
Applications
• Industrial Ethernet Networks – Provides reliable communication between controllers, HMIs, drives, and I/O devices.
• Manufacturing Automation – Supports machine-level and plant-wide networking infrastructure.
• Process Control Systems – Connects automation devices in chemical, oil and gas, and utility applications.
• Power Generation Facilities – Enables secure communication between monitoring and control systems.
• Water and Wastewater Treatment Plants – Supports networked control and data acquisition systems.
• Packaging Machinery – Provides high-performance communication for automated production lines.
• Material Handling Systems – Connects conveyors, sorters, and logistics equipment.
• Mining Operations – Supports rugged industrial communication networks.
• Transportation Infrastructure – Enables communication between industrial control devices.
• Industrial Data Collection Systems – Facilitates reliable transfer of operational and production data.
Advantages
• 16 Fast Ethernet Ports – Supports connectivity for a large number of industrial devices.
• Gigabit Combo Ports – Provides flexible copper or fiber uplink options.
• CIP Sync Support – Enables accurate time synchronization across EtherNet/IP devices.
• Managed Network Functionality – Offers advanced monitoring, diagnostics, and configuration capabilities.
• Redundant Power Inputs – Improves network availability and system reliability.
• Industrial-Grade Design – Built for demanding automation environments.
• Flexible Network Expansion – Supports scalable industrial network architectures.
• Fiber Connectivity Option – Allows long-distance and noise-immune communications using SFP modules.
• Enhanced Network Security – Supports managed switch features for controlled network access.
• Seamless Integration – Works effectively with Allen-Bradley and EtherNet/IP-based systems.
