Allen Bradley 1784-PCICS ControlNet Universal PCI Communication Interface Card
- Product Details
- FAQs
- Related
- Contact Us
- Packing & Delivery
- Product Ratings
Product Introduction
The Allen-Bradley 1784-PCICS ControlNet Universal PCI Communication Interface Card is a high-performance industrial communication module designed to connect a personal computer to a ControlNet network. It enables engineers to perform configuration, monitoring, diagnostics, and maintenance of ControlNet-based automation systems directly from a PC.
This interface card supports dual-channel communication, allowing simultaneous access to ControlNet networks for improved flexibility and system efficiency. It is commonly used as an I/O bridge card, enabling data exchange between PC-based applications and distributed industrial control systems.
Designed for PCI bus architecture, the 1784-PCICS integrates into modern industrial PCs while maintaining compatibility with ControlNet networks via dual BNC connectors. It provides deterministic, high-speed communication essential for time-critical automation environments.
Product Specifications
| Parameter | Value |
|---|---|
| Product Type | Communication Interface Card |
| Series | ControlNet |
| Model Number | 1784-PCICS |
| Bus Interface | PCI Bus |
| Network Type | ControlNet |
| Function | I/O bridge card |
| Channel Configuration | 2-channel communication |
| Connector Type | 2 BNC connectors |
| Capabilities | ControlNet monitoring and configuration |
| Communication Mode | Deterministic real-time communication |
| Installation Type | PCI slot mounted |
| Application Area | Industrial automation and network diagnostics |
| Dimensions | 165 × 107 mm |
| Weight | 0.18 kg |
Applications
• ControlNet network configuration
Used for setting up and configuring ControlNet industrial networks from a PC environment.
• Industrial system monitoring
Enables real-time monitoring of network status and device communication performance.
• Automation system diagnostics
Supports troubleshooting of ControlNet-connected PLC and I/O systems.
• Engineering workstation integration
Allows PCs to act as engineering stations for industrial control system management.
• Data communication bridging
Functions as an I/O bridge between PC applications and ControlNet networks.
Advantages
• Dual-channel ControlNet access
Supports simultaneous communication with multiple network segments.
• PCI bus integration
Easily installs into modern industrial PCs with standard PCI architecture.
• Deterministic communication
Ensures stable and predictable data exchange for real-time control systems.
• Efficient monitoring capability
Provides comprehensive tools for network diagnostics and performance tracking.
• Industrial-grade reliability
Designed for stable operation in harsh automation environments.
• Flexible system integration
Works as a communication bridge between PC-based systems and ControlNet networks.
FAQ
- What is the main function of the 1784-PCICS card?
It connects a PC to a ControlNet network for monitoring, configuration, and diagnostics of industrial systems. - What does “I/O bridge card” mean?
It means the card acts as a communication bridge between PC applications and ControlNet I/O networks. - How many communication channels does it support?
It supports two independent ControlNet communication channels. - What type of bus interface does it use?
It uses a PCI bus interface for installation in industrial computers. - What are the BNC connectors used for?
They are used to physically connect the card to the ControlNet network media. - Can it be used for real-time control?
It supports deterministic communication, but it is mainly used for monitoring and configuration tasks. - Is it compatible with modern Ethernet systems?
No, it is designed specifically for ControlNet networks. - What are common installation issues?
Improper PCI slot installation, incorrect network termination, and driver configuration issues. - Can it be used for troubleshooting PLC systems?
Yes, it is widely used for diagnostics and troubleshooting of ControlNet-connected PLC systems. - Is it still used in modern automation systems?
It is mainly used in legacy or existing ControlNet installations rather than new Ethernet-based systems.
Related Models
| Model | Description |
|---|---|
| 1784-PCIC | ControlNet PCI communication card |
| 1784-PCIDS | DeviceNet PCI interface card |
| 1784-KTCX15 | ControlNet ISA/EISA interface card |
| 1784-PKTX | PC communication adapter |
| 1784-PCMK | PCMCIA communication card |
| 1784-KTXD | DH+/RIO communication card |
Popular Models
| Model | Description |
|---|---|
| 1756-EN2T | Ethernet communication module |
| 1756-CN2R | ControlNet bridge module |
| 1756-IB16 | Digital input module |
| 1756-OB32 | Digital output module |
| 1769-L33ER | CompactLogix controller |
| 1734-AENTR | POINT I/O Ethernet adapter |
