Allen Bradley 20-COMM-ER PowerFlex EtherNet/IP Dual Port Communication Adapter
- Product Details
- FAQs
- Related
- Contact Us
- Packing & Delivery
- Product Ratings
Product Introduction
The Allen-Bradley 20-COMM-ER PowerFlex EtherNet/IP Dual Port Communication Adapter is a high-performance communication interface designed for SMC and PowerFlex 7-class drive systems. It enables seamless integration of drives into EtherNet/IP industrial networks, supporting advanced control, monitoring, and diagnostics functions.
This adapter features a dual-port Ethernet design, allowing it to operate as an embedded switch within the network. It supports flexible network topologies such as star and linear (daisy-chain), reducing the need for external Ethernet switches and simplifying system wiring.
The 20-COMM-ER converts internal drive communication via DPI (Drive Peripheral Interface) into EtherNet/IP protocol, ensuring real-time data exchange with PLC systems. Its compact design allows direct installation onto compatible drives, making it an efficient solution for upgrading communication capabilities in industrial automation systems.
Product Specifications
| Parameter | Description |
|---|---|
| Product Model | 20-COMM-ER |
| Manufacturer | Rockwell Automation (Allen-Bradley) |
| Product Type | Dual-port EtherNet/IP communication adapter |
| Compatible Systems | SMC / PowerFlex 7-class drives |
| Communication Protocol | EtherNet/IP (DPI to Ethernet) |
| Ethernet Ports | Dual-port (integrated switch) |
| Ethernet Speed | 10/100 Mbps |
| Supply Voltage | 5 VDC |
| Function | Drive communication interface module |
| Network Topology Support | Star, Linear (daisy-chain) |
| Mounting Type | Drive-mounted adapter |
| Functionality | Real-time control, monitoring, diagnostics |
| Dimensions | 86 × 19 × 78.5 mm |
| Weight | 0.085 kg |
Applications
● Industrial Ethernet drive integration
Enables SMC and PowerFlex 7-class drives to connect to EtherNet/IP automation networks.
● Distributed control systems
Supports multi-drive systems where several devices are connected in linear or star network configurations.
● Manufacturing automation lines
Used in production environments requiring coordinated motor control and centralized monitoring.
● System upgrade and modernization
Provides a pathway to upgrade legacy drive systems to Ethernet-based communication architectures.
● Industrial motion and process control
Facilitates real-time communication between PLCs and drives in automation systems.
Advantages
● Dual-port Ethernet functionality
Acts as an embedded switch, allowing daisy-chain connections without external networking hardware.
● Flexible network topology support
Supports star and linear configurations, simplifying network design.
● Seamless DPI to EtherNet/IP conversion
Enables efficient communication between internal drive systems and Ethernet networks.
● Compact and easy installation
Direct mounting on drives reduces wiring complexity and saves cabinet space.
● Reliable industrial communication
Provides stable and deterministic data exchange for automation control.
● Cost-effective system expansion
Reduces the need for additional switches and network components.
FAQ
- What is the main function of the 20-COMM-ER adapter?
It enables SMC and PowerFlex 7-class drives to communicate over EtherNet/IP networks, supporting real-time control and monitoring. - What is the benefit of dual Ethernet ports?
Dual ports allow the module to act as a switch, enabling daisy-chain connections and reducing the need for external Ethernet switches. - What network topologies are supported?
It supports star and linear (daisy-chain) network configurations, offering flexibility in system design. - What is DPI in this module?
DPI is the internal drive communication interface that the adapter converts into EtherNet/IP protocol. - Is this module compatible with all PowerFlex drives?
It is designed for PowerFlex 7-class drives and SMC systems, not all PowerFlex models. - How is the module powered?
It uses a 5 VDC supply from the drive, ensuring efficient operation with minimal power consumption. - Does it support real-time communication?
Yes, it provides deterministic communication suitable for industrial automation and motion control. - What happens if one Ethernet port fails?
Depending on the network configuration, communication may be interrupted or rerouted if redundancy is implemented externally. - Is configuration required after installation?
Yes, IP addressing and network parameters must be configured to integrate into the control system. - What is the main advantage over single-port adapters?
The dual-port design simplifies wiring, reduces hardware requirements, and improves network flexibility.
Related Models
| Model | Description | Key Feature |
|---|---|---|
| 20-COMM-E | EtherNet/IP adapter | Single-port Ethernet |
| 20-COMM-D | ControlNet adapter | Deterministic fieldbus |
| 20-COMM-DP | Profibus adapter | Profibus DP integration |
| 20-COMM-DR | DeviceNet adapter | Device-level network |
| 20-COMM-R | Remote I/O adapter | Legacy I/O interface |
| 20-COMM-IO | I/O module | General communication interface |
Popular Models
| Model | Description | Key Feature |
|---|---|---|
| 20F11ND014AA0NNNNN | PowerFlex 753 drive | Industrial motor control |
| 20G11NC072JA0NNNNN | PowerFlex 755 drive | Advanced drive platform |
| 1756-L81E | ControlLogix controller | PLC automation system |
| 1756-EN2T | Ethernet module | High-speed networking |
| 1769-L33ER | CompactLogix controller | Integrated automation |
| 1734-IB8 | POINT I/O module | Compact input solution |
