Allen Bradley 2198-KITCON-D057 Kinetix 5700 Connector Kit

Product Introduction

The Allen Bradley 2198-KITCON-D057 Kinetix 5700 Connector Kit is an accessory kit designed for the Kinetix 5700 servo drive platform, providing the necessary connector interfaces for reliable drive integration in industrial motion control systems. It is used to ensure proper electrical connection between the servo drive and external system wiring, supporting safe and structured installation.

This connector kit is intended to simplify field wiring while maintaining high signal integrity and secure mechanical fastening. It includes dedicated interface provisions for motor power, feedback, I/O signals, and safety functions such as STO (Safe Torque Off), making it a key component in achieving a complete servo system configuration.

By standardizing connection interfaces, the 2198-KITCON-D057 helps reduce wiring errors, improve installation efficiency, and ensure consistent system performance in demanding automation environments.

---

Product Specifications

---

Applications

• Used in servo drive installation systems to provide standardized wiring connections between Kinetix 5700 drives and external components

• Applicable in motion control systems such as robotics, packaging machines, and high-speed automation lines

• Supports motor power and feedback wiring ensuring stable and reliable servo motor operation

• Integrates safety functions (STO) for secure torque-off control in emergency or maintenance conditions

• Used in OEM machine builds where consistent and modular servo wiring is required

---

Advantages

• Simplifies servo drive wiring by providing pre-defined connection interfaces for key signal groups

• Improves installation reliability by reducing wiring errors and ensuring correct pin configuration

• Supports safety integration (STO function) for enhanced machine protection

• Enhances system organization with clearly separated connection groups for power, I/O, and control

• Reduces commissioning time by standardizing connection structure across Kinetix 5700 systems

• Robust industrial design ensures stable performance in vibration and harsh environments

FAQ

1. What is the main purpose of the 2198-KITCON-D057 connector kit?
   It is used to provide standardized electrical connections for Kinetix 5700 servo drives, covering power, I/O, and safety interfaces.
2. What does MP stand for in this kit?
   MP refers to motor power connections used to supply power to the servo motor from the drive.
3. What is the function of BC connectors?
   BC refers to brake control connections used to manage motor braking functions.
4. What does I/O connection support in this kit?
   The I/O connectors handle control and signal communication between the servo drive and external devices.
5. What is STO in this connector kit?
   STO stands for Safe Torque Off, a safety function that disables motor torque in emergency or maintenance situations.
6. Is this kit required for all Kinetix 5700 installations?
   It is typically required to ensure proper wiring and full functionality of the drive system.
7. Does this connector kit affect system performance?
   It does not process signals but ensures reliable and stable physical connections, which indirectly supports system performance.
8. Is the installation of this kit complex?
   No, it is designed to simplify installation by providing pre-structured connection interfaces.
9. Can this kit improve system safety?
   Yes, especially through the integrated STO interface which supports safe shutdown of torque.
10. What types of systems commonly use this connector kit?
    It is commonly used in robotics, packaging systems, and high-performance industrial automation equipment using Kinetix 5700 drives.
