GE DS200FGPAG1ALD Field Gate Pulse Amplifier Driver
- Product Details
- FAQs
- Related
- Contact Us
- Packing & Delivery
- Product Ratings
What This Board Does
The GE DS200FGPAG1ALD is an advanced field gate pulse amplifier driver board designed for GE DS200 series drive control systems. It delivers high-current gate pulses required to reliably switch power devices in inverter and frequency converter applications. This ensures rapid, precise turn-on and turn-off of semiconductor devices like IGBTs and MOSFETs, enhancing efficiency and thermal performance in heavy-duty industrial drives.
Engineered for rugged, high-throughput environments, this module is ideal when dependable gate drive performance matters most.
Technical Specifications & Physical Attributes
| Specification | Description |
|---|---|
| Module Type | Field Gate Pulse Amplifier Driver |
| Compatible Systems | GE DS200 Drive & Control Systems |
| Primary Function | High-current gate pulse generation |
| Signal Output | Amplified drive pulses for power devices |
| Isolation | Electrical isolation between logic and power stages |
| Mounting Style | Rack-mounted or panel-integrated installation |
| Operating Temperature | –10°C to +60°C |
| Storage Temperature | –25°C to +85°C |
| Humidity Range | 5–90% RH, non-condensing |
| Dimensions (H × W × D) | 180 mm × 62 mm × 150 mm |
| Weight | Approx. 0.78 kg |
| Construction Quality | Industrial PCB with reinforced connectors |
Where This Board Is Used
-
High-power inverter drive systems
-
Industrial motor control cabinets
-
Semiconductor gate pulse management in VFDs
-
Drive subsystem retrofits and upgrades
-
Replacement of aging amplifier driver boards
-
Sites requiring high current, high-speed gate switching
Module Strengths & Benefits
-
High Current Gate Drive: Provides strong pulse output to ensure reliable switching.
-
Rugged Industrial Design: Built for extended duty in harsh electrical environments.
-
Electrical Separation: Galvanic isolation enhances signal safety and control integrity.
-
Compatibility with Legacy Equipment: Designed for smooth integration into DS200 systems.
-
Service-Ready Layout: Accessible connectors and labeling simplify maintenance.
Contact for Purchasing & Expert Support
Looking for GE drive system boards, gate drivers, or urgent spares? Our team delivers 24/7 global support, rapid logistics, and technical consultation to keep your industrial systems running with minimal downtime.
Sales and Business Development
-
Phone: +86 13666033393
-
E-mail: [email protected]
-
WhatsApp: +86 13666033393
-
Business Hours: 7×24
-
Address: Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China
Contact us for pricing, availability, compatibility checks, or engineering support.
Frequently Asked Questions
-
What is the purpose of the DS200FGPAG1ALD module?
It amplifies and delivers gate pulses for high-current switching in drive systems. -
Which systems use this board?
GE DS200 series drive and control platforms. -
Is this board critical for inverter operations?
Yes — precise gate pulses are key to power device switching. -
Can it replace older gate driver modules?
Yes, it is frequently used in upgrades and legacy replacements. -
Does it provide electrical isolation?
Yes — the design includes separation between logic and power circuits. -
Is calibration required?
No board-level calibration is typically needed. -
Is it suitable for continuous industrial service?
Yes — built to withstand ongoing heavy-duty operation. -
How is it installed?
It mounts directly into the DS200 control rack or panel. -
What environmental conditions can it handle?
Operating range: –10°C to +60°C, up to 90% non-condensing humidity. -
What is the expected service life?
Properly installed, it delivers many years of reliable performance.
