GE Fanuc IC200MDL330 VersaMax Discrete Output Modules
- Product Details
- FAQs
- Related
- Contact Us
- Packing & Delivery
- Product Ratings
Product Overview
The GE Fanuc IC200MDL330 VersaMax Discrete Output Module is a high-performance 8-point DC output module designed for reliable control of field devices in automation systems. It is part of the GE VersaMax PLC family, providing robust and compact I/O solutions for industrial control applications.
Key Features
-
8-point DC discrete output module for GE VersaMax PLCs
-
Supports 12/24 VDC positive logic (sourcing) outputs
-
Individually isolated channels for flexible wiring
-
Integrated output status LEDs for quick diagnostics
-
Short-circuit and overcurrent protection
-
Compact modular design for space-efficient installation
-
Reliable operation in industrial automation environments
Technical Specifications
| Specification | Details |
|---|---|
| Model | IC200MDL330 |
| Type | Discrete Output Module |
| Supported System | GE Fanuc VersaMax PLC |
| Number of Output Points | 8 |
| Output Type | DC, positive logic (sourcing) |
| Output Voltage Range | 12/24 VDC nominal |
| Output Current per Point | 0.5 A maximum |
| Total Module Current | 4.0 A maximum |
| Output Delay (ON/OFF) | 0.5 ms typical |
| Isolation | 1500 V between field and logic circuits |
| Protection | Short-circuit and overcurrent protection |
| Indicators | 8 individual output status LEDs |
| Power Requirements | 5 VDC from backplane, 60 mA typical |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | –40 °C to +85 °C |
| Mounting | DIN rail or panel mount |
| Dimensions | 110 x 66.8 x 50 mm |
| Weight | 0.45 kg |
Frequently Asked Questions (FAQ)
1. What is the primary function of the IC200MDL330 module?
It provides 8 DC output channels for controlling field devices such as solenoids, lamps, and relays.
2. What is the output type of this module?
It features positive logic (sourcing) outputs for 12/24 VDC applications.
3. How many output points are available?
There are 8 individually isolated DC output channels.
4. What is the maximum current per output point?
Each output channel supports up to 0.5 A, with a total module current of 4.0 A.
5. Does the module include protection features?
Yes, it includes built-in short-circuit and overcurrent protection.
6. How can output status be monitored?
Each output channel has a dedicated LED indicator showing its ON/OFF status.
7. What type of isolation does it provide?
It provides 1500 V isolation between field and logic circuits for signal integrity and noise protection.
8. What are the dimensions of the IC200MDL330 module?
The dimensions are 110 x 66.8 x 50 mm.
9. How is it powered?
The module is powered from the VersaMax backplane at 5 VDC, drawing approximately 60 mA.
10. Where is this module commonly used?
It is typically used in discrete automation applications such as machine control, packaging systems, and process monitoring.
Related GE Fanuc Models
