GE IC693PWR322 Series 90-30 Power Supply Module
- Product Details
- FAQs
- Related
- Contact Us
- Packing & Delivery
- Product Ratings
Product Overview
The GE IC693PWR322 is a standard power supply module for the Series 90-30 PLC system. It operates on 24/48 VDC and is designed to provide reliable power to various modules within the system. It mounts easily into a standard power slot and supports multiple voltage outputs.
Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | IC693PWR322 |
| Series | GE Series 90-30 |
| Input Voltage | 24/48 VDC |
| Output Voltages | +5VDC, +24VDC Relay, +24VDC Isolated |
| Output Power Capacity | 30 Watts total |
| +5VDC Output Power | 30 Watts (Max 7A) |
| +24VDC Relay Output Power | 15 Watts |
| +24VDC Isolated Output Power | 20 Watts |
| Ride-Through Time | ≥10 ms |
| Indicators | PWR, OK, RUN, BATT LEDs |
| Communication Port | RS-485 (SNP Protocol) |
| Battery Backup | Supported (Lithium, IC693ACC301) |
| Dimensions (W x D x H) | 129 x 52 x 117 mm |
| Weight | 0.5 kg |
Applications
-
Industrial automation and process control
-
Power distribution in modular PLC racks
-
Reliable power supply for relay and input modules
-
Backup memory support in critical control systems
Product Advantages
-
Supports multiple voltage outputs from a single unit
-
Built-in protection against overcurrent and surge
-
Compact size for efficient panel integration
-
Integrated RS-485 port for serial communication
-
LED indicators for fast diagnostics
-
Easily replaceable battery for RAM memory backup
Frequently Asked Questions (FAQ)
Q1: What is the input voltage range for IC693PWR322?
A1: The module supports 24 or 48 VDC nominal input.
Q2: Can this power supply be used with expansion baseplates?
A2: It is designed for use with CPU baseplates; not suitable for remote or expansion units.
Q3: What types of outputs does the power supply provide?
A3: It provides +5VDC, +24VDC Isolated, and +24VDC Relay outputs.
Q4: What happens if the output is overloaded?
A4: The module shuts down and auto-recovers when the overload is cleared.
Q5: Is there a battery included with the module?
A5: No, the lithium battery must be ordered separately (IC693ACC301).
Q6: How is communication handled through the module?
A6: Through an RS-485 compatible serial port supporting SNP protocol.
Q7: What do the status LEDs indicate?
A7: They show power status (PWR), PLC health (OK), PLC mode (RUN), and battery status (BATT).
Q8: How much total output power can the unit deliver?
A8: It delivers a combined maximum of 30 Watts across all outputs.
Q9: Does the module support memory backup during power loss?
A9: Yes, with a backup lithium battery installed.
Q10: Can I perform Hi-Pot tests with the unit installed?
A10: Yes, but the internal jumper for overvoltage protection must be temporarily removed.
Related GE Series 90-30 Models
| Model Number | Description | Input Voltage | Output Power | Dimensions (mm) | Weight |
|---|---|---|---|---|---|
| IC693PWR321 | Power Supply, 120/240 VAC Input | 120/240 VAC | 30W | 129 x 52 x 117 | 0.5 kg |
| IC693PWR330 | High Capacity, 120/240 VAC Input | 120/240 VAC | 60W | 129 x 52 x 117 | 0.6 kg |
| IC693PWR331 | High Capacity, 125 VDC Input | 125 VDC | 60W | 129 x 52 x 117 | 0.6 kg |
| IC693PWR332 | 12 VDC Input, High Capacity | 12 VDC | 30W | 129 x 52 x 117 | 0.5 kg |
| IC693CHS391 | 10-Slot Standard Baseplate | — | — | 356 x 101 x 117 | 1.2 kg |
| IC693CHS392 | 5-Slot Compact Baseplate | — | — | 179 x 101 x 117 | 0.8 kg |
Popular GE Fanuc Models
| Model Number | Description | Category | Power Supply | Dimensions (mm) | Weight |
|---|---|---|---|---|---|
| IC695CPU310 | PACSystems RX3i CPU | CPU Module | External | 165 x 41 x 119 | 0.35 kg |
| IC693CPU374 | CPU w/ Ethernet for Series 90-30 | CPU Module | Internal | 129 x 52 x 117 | 0.45 kg |
| IC695CHS012 | RX3i 12-Slot Universal Backplane | Baseplate | — | 432 x 102 x 150 | 1.8 kg |
| IC200PWR101 | VersaMax Power Supply, 120/240 VAC | Power Supply | 120/240 VAC | 110 x 70 x 75 | 0.35 kg |
| IC200MDL650 | VersaMax 32-Point Digital Input Module | I/O Module | — | 130 x 40 x 75 | 0.25 kg |
| IC200MDL241 | VersaMax 16-Point Output Relay Module | I/O Module | — | 130 x 40 x 75 | 0.25 kg |
Frequently Asked Questions (FAQ)
Q1: What is the input voltage range for IC693PWR322?
A1: The module supports 24 or 48 VDC nominal input.
Q2: Can this power supply be used with expansion baseplates?
A2: It is designed for use with CPU baseplates; not suitable for remote or expansion units.
Q3: What types of outputs does the power supply provide?
A3: It provides +5VDC, +24VDC Isolated, and +24VDC Relay outputs.
Q4: What happens if the output is overloaded?
A4: The module shuts down and auto-recovers when the overload is cleared.
Q5: Is there a battery included with the module?
A5: No, the lithium battery must be ordered separately (IC693ACC301).
Q6: How is communication handled through the module?
A6: Through an RS-485 compatible serial port supporting SNP protocol.
Q7: What do the status LEDs indicate?
A7: They show power status (PWR), PLC health (OK), PLC mode (RUN), and battery status (BATT).
Q8: How much total output power can the unit deliver?
A8: It delivers a combined maximum of 30 Watts across all outputs.
Q9: Does the module support memory backup during power loss?
A9: Yes, with a backup lithium battery installed.
Q10: Can I perform Hi-Pot tests with the unit installed?
A10: Yes, but the internal jumper for overvoltage protection must be temporarily removed.
Related GE Series 90-30 Models
| Model Number | Description | Input Voltage | Output Power | Dimensions (mm) | Weight |
|---|---|---|---|---|---|
| IC693PWR321 | Power Supply, 120/240 VAC Input | 120/240 VAC | 30W | 129 x 52 x 117 | 0.5 kg |
| IC693PWR330 | High Capacity, 120/240 VAC Input | 120/240 VAC | 60W | 129 x 52 x 117 | 0.6 kg |
| IC693PWR331 | High Capacity, 125 VDC Input | 125 VDC | 60W | 129 x 52 x 117 | 0.6 kg |
| IC693PWR332 | 12 VDC Input, High Capacity | 12 VDC | 30W | 129 x 52 x 117 | 0.5 kg |
| IC693CHS391 | 10-Slot Standard Baseplate | — | — | 356 x 101 x 117 | 1.2 kg |
| IC693CHS392 | 5-Slot Compact Baseplate | — | — | 179 x 101 x 117 | 0.8 kg |
Popular GE Fanuc Models
| Model Number | Description | Category | Power Supply | Dimensions (mm) | Weight |
|---|---|---|---|---|---|
| IC695CPU310 | PACSystems RX3i CPU | CPU Module | External | 165 x 41 x 119 | 0.35 kg |
| IC693CPU374 | CPU w/ Ethernet for Series 90-30 | CPU Module | Internal | 129 x 52 x 117 | 0.45 kg |
| IC695CHS012 | RX3i 12-Slot Universal Backplane | Baseplate | — | 432 x 102 x 150 | 1.8 kg |
| IC200PWR101 | VersaMax Power Supply, 120/240 VAC | Power Supply | 120/240 VAC | 110 x 70 x 75 | 0.35 kg |
| IC200MDL650 | VersaMax 32-Point Digital Input Module | I/O Module | — | 130 x 40 x 75 | 0.25 kg |
| IC200MDL241 | VersaMax 16-Point Output Relay Module | I/O Module | — | 130 x 40 x 75 | 0.25 kg |
