Allen Bradley 1746-IN16/C SLC 500 Digital Input Module
- Product Details
- FAQs
- Related
- Contact Us
- Packing & Delivery
- Product Ratings
Product Introduction
The Allen Bradley 1746-IN16/C SLC 500 Digital Input Module is a Series C version of the standard 16-channel digital input module designed for the SLC 500 platform by Rockwell Automation. It is specifically engineered to interface field input devices with the controller, ensuring accurate and stable signal acquisition in industrial environments.
Supporting both 24V AC and DC input signals, this module offers strong flexibility in mixed-signal systems. The Series C revision introduces incremental improvements in reliability and noise immunity, making it better suited for demanding industrial conditions. With 16 input points sharing a common reference, the module simplifies wiring while maintaining consistent performance.
The 1746-IN16/C is widely used in legacy automation systems and remains a dependable choice for maintenance, system expansion, and replacement applications within existing SLC 500 installations.
Product Specifications
| Parameter | Value |
|---|---|
| Module Type | SLC 500 Digital Input Module (Series C) |
| Input Type | Digital AC/DC |
| Number of Inputs | 16 Points |
| Input Voltage Range | 24 V AC/DC |
| Frequency Range | 50/60 Hz |
| Points per Common | 16 |
| Input Current (Typical) | ~8 mA @ 24V |
| Signal Delay (On/Off) | Typical 8–12 ms |
| Backplane Current | Approx. 0.085 A @ 5V |
| Isolation | Electrical Isolation Between Field and Backplane |
| Wiring Configuration | Shared Common |
| Status Indicators | Individual LED per Channel |
| Operating Temperature | 0 to 60°C |
| Storage Temperature | -40 to 85°C |
| Humidity | 5–95% non-condensing |
| Mounting | Chassis-based (SLC 500 Rack) |
| Dimensions | 144.5 × 34.6 × 130.18 mm |
| Weight | 0.27 kg |
Applications
● Used for collecting digital signals from push buttons, limit switches, and proximity sensors
● Suitable for mixed AC/DC input environments, improving system flexibility
● Applied in manufacturing automation systems, especially legacy SLC 500 installations
● Common in process industries, where stable and reliable input monitoring is essential
● Ideal for equipment retrofitting and system upgrades, maintaining compatibility with existing hardware
● Used in material handling and packaging systems, ensuring accurate status feedback
Advantages
● Supports both AC and DC input signals, reducing the need for multiple module types
● Provides 16 input channels in a single slot, optimizing rack space usage
● Series C version offers enhanced noise immunity and improved reliability
● Integrated LED indicators for each channel, simplifying troubleshooting
● Ensures seamless integration with SLC 500 systems, avoiding complex reconfiguration
● Proven long-term stability in industrial automation environments
FAQ
- What is the difference between Series C and earlier versions?
Series C typically includes internal improvements such as better noise filtering and enhanced reliability, while maintaining full compatibility with earlier systems. - Can AC and DC inputs be used on the same module?
Yes, the module supports both types, but proper wiring practices must be followed to ensure stable operation. - What types of signals are suitable for this module?
It is designed for standard industrial discrete signals such as switches, relays, and sensor outputs. - How are the input channels grouped?
All 16 inputs share a common reference, which simplifies wiring but requires careful grounding design. - Does the module include diagnostic features?
Yes, each channel has an LED indicator to display input status in real time. - Is this module suitable for high-speed signal detection?
No, it is intended for standard-speed industrial signals; high-speed applications require specialized modules. - How does the module handle electrical interference?
It incorporates filtering and isolation to reduce the impact of electrical noise on signal accuracy. - What happens if incorrect voltage is applied?
Applying voltage outside the specified range may damage the module or result in unreliable operation. - Can this module be used in new automation projects?
It is mainly intended for existing SLC 500 systems, as newer platforms are available for new installations. - What is the main benefit of using this module in legacy systems?
It ensures compatibility, reliability, and ease of integration without requiring major system redesign.
Related Models
| Model | Description | Channels | Voltage |
|---|---|---|---|
| 1746-IN16 | Digital Input Module | 16 Inputs | 24 V AC/DC |
| 1746-IB16 | DC Input Module | 16 Inputs | 24 VDC |
| 1746-IA16 | AC Input Module | 16 Inputs | 120 VAC |
| 1746-OB16 | Digital Output Module | 16 Outputs | 24 VDC |
| 1746-OW16 | Relay Output Module | 16 Outputs | AC/DC |
| 1746-NI4 | Analog Input Module | 4 Inputs | Analog |
