Allen Bradley 1756-ENBT ControlLogix EtherNet/IP Bridge Module
- Product Details
- FAQs
- Related
- Contact Us
- Packing & Delivery
- Product Ratings
Product Introduction
The Allen Bradley 1756-ENBT ControlLogix EtherNet/IP Bridge Module is designed to provide reliable Ethernet/IP communication between ControlLogix controllers and Ethernet-based industrial devices. It enables high-speed data exchange with I/O modules, drives, HMIs, and supervisory systems, forming a critical link between the controller backplane and plant networks.
As a widely used communication module in ControlLogix systems, the 1756-ENBT supports deterministic communication and stable network performance. Its proven design makes it suitable for a broad range of industrial automation applications requiring consistent and dependable Ethernet connectivity.
Product Specifications
| Parameter | Specification |
|---|---|
| Product Type | EtherNet/IP Communication Module |
| Manufacturer | Allen Bradley |
| Series | ControlLogix |
| Model / Part Number | 1756-ENBT |
| Network Protocol | EtherNet/IP |
| Controller Communication | ControlLogix backplane |
| Backplane Current | 700 mA @ 5 V DC |
| Auxiliary Current | 3 mA @ 24 V DC |
| Insulation Voltage | 30 V continuous |
| Power Dissipation | 3.7 W |
| Thermal Dissipation | 12.6 BTU/hr |
| Enclosure Type | Open |
| Slot Width | 1 slot |
| Installation Location | ControlLogix chassis, any slot |
| Operating Temperature | 0 to 60 °C |
| Dimensions | 144.5 × 34.6 × 130.18 mm |
| Weight | 0.23 kg |
Applications
• EtherNet/IP Industrial Networks
Provides communication between ControlLogix controllers and Ethernet-based field devices.
• Distributed I/O Systems
Connects remote I/O racks and intelligent devices to the controller over Ethernet/IP.
• Manufacturing Automation
Used in assembly lines, packaging systems, and material handling applications.
• Process Control Systems
Supports communication in continuous and batch process environments.
• HMI and SCADA Connectivity
Enables data exchange between controllers and visualization or supervisory systems.
• Plant Network Integration
Forms a bridge between control-level systems and plant-wide Ethernet networks.
Advantages
• Proven EtherNet/IP Performance
Widely deployed design with reliable and predictable communication behavior.
• Seamless ControlLogix Integration
Installs directly into ControlLogix chassis and communicates through the backplane.
• Deterministic Data Exchange
Supports time-critical industrial control applications.
• Efficient Power and Thermal Design
Optimized for stable operation within control cabinets.
• Flexible Installation
Can be installed in any available ControlLogix chassis slot.
• Broad Application Compatibility
Supports a wide range of Ethernet/IP devices and automation architectures.
FAQ
-
What is the main role of the 1756-ENBT module?
It provides EtherNet/IP communication between ControlLogix controllers and Ethernet-based devices. -
Is the module compatible with standard ControlLogix chassis?
Yes, it can be installed in any slot of a ControlLogix chassis. -
Does it support real-time industrial communication?
Yes, it supports deterministic EtherNet/IP communication for control applications. -
Can it be used with distributed I/O systems?
Yes, it is commonly used to connect remote I/O and intelligent devices. -
Is the module suitable for continuous industrial operation?
Yes, it is designed for 24/7 operation in industrial automation environments. -
Does it support communication with HMIs and SCADA systems?
Yes, it enables reliable data exchange with visualization and supervisory platforms. -
How does the module communicate with the controller?
It communicates through the ControlLogix backplane. -
Is the enclosure closed or open?
It uses an open-style enclosure intended for installation inside control cabinets. -
Can it be used in both discrete and process automation systems?
Yes, it is suitable for a wide range of industrial automation applications. -
Is the 1756-ENBT still widely used in existing systems?
Yes, it remains commonly deployed in many installed ControlLogix platforms.
Related Models
| Model Number | Description |
|---|---|
| 1756-EN2T | High-Performance EtherNet/IP Module |
| 1756-EN2TR | Embedded Switch Ethernet Module |
| 1756-EN3TR | Redundant Ethernet Module |
| 1756-EN2TXT | Extreme Environment Ethernet Module |
| 1756-DNB | DeviceNet Scanner Module |
| 1756-CNB | ControlNet Communication Module |
Popular Models
| Model Number | Description |
|---|---|
| 1756-ENBT | Standard EtherNet/IP Module |
| 1756-EN2T | High-Performance Ethernet Module |
| 1756-EN2TR | Embedded Switch Ethernet Module |
| 1756-EN3TR | Redundant Ethernet Module |
| 1756-DNB | DeviceNet Scanner Module |
| 1756-CNB | ControlNet Module |
