Allen Bradley 1761-L16BBB MicroLogix 1000 Programmable Controller
- Product Details
- FAQs
- Related
- Contact Us
- Packing & Delivery
- Product Ratings
Product Introduction
The Allen-Bradley 1761-L16BBB is a MicroLogix 1000 programmable controller designed for compact automation systems and small OEM machines. Operating on 24V DC, it combines 10 digital inputs, 4 sourcing outputs, and 2 relay (digital contact) outputs, providing versatile control options for a wide range of industrial and machine-level automation applications.
With a power consumption of only 5 watts, this controller is energy-efficient while delivering reliable logic control for motor starters, alarms, solenoids, and sequencing processes. Its small footprint allows easy panel mounting and integration into compact control cabinets.
Product Specifications
| Parameter | Description |
|---|---|
| Model Number | 1761-L16BBB |
| Product Series | MicroLogix 1000 |
| Controller Type | Compact PLC |
| Power Supply | 24 VDC |
| Digital Inputs | 10 × 24V DC |
| Sourcing Outputs | 4 × DC Sourcing Outputs |
| Relay Outputs | 2 × Digital Contact Outputs |
| Power Consumption | 5 W |
| User Memory | 1 KB EEPROM |
| Communication Port | RS-232 Serial Port |
| Programming Software | RSLogix 500 |
| Mounting Type | DIN Rail / Panel Mount |
| Dimensions | 120 × 40 × 80 mm |
| Weight | 0.29 kg |
Applications
● Standalone machine automation for OEM or small industrial equipment.
● Motor starter and solenoid control using sourcing and relay outputs.
● Alarm and signal logic systems.
● Basic sequencing and interlocking in compact panels.
● Small process control applications requiring DC power.
● Energy-efficient control systems with low power consumption.
Advantages
● Mixed output capability with sourcing DC outputs and relay outputs.
● Low power consumption at only 5 W, suitable for energy-sensitive applications.
● Integrated 24V DC supply simplifies wiring.
● Compact footprint for panel-mount applications.
● Reliable non-volatile memory with 1 KB EEPROM.
● Easy programming using RSLogix 500.
FAQ
-
What power supply does the 1761-L16BBB require?
It operates on 24 VDC. -
How many digital inputs and outputs are available?
10 digital inputs, 4 DC sourcing outputs, and 2 relay outputs. -
What type of outputs are provided?
4 DC sourcing outputs and 2 relay (digital contact) outputs. -
What is the controller’s power consumption?
It consumes approximately 5 watts. -
How much user memory is available?
1 KB EEPROM memory for program storage. -
Which software is used for programming?
RSLogix 500 software. -
Can it control motors and solenoids?
Yes, the mixed outputs allow control of small motors and solenoids. -
Is external 24V required for digital inputs?
No, the integrated 24V DC supply powers the inputs. -
Can it be DIN rail or panel mounted?
Yes, it supports both DIN rail and panel mounting. -
What applications is this controller best suited for?
Standalone OEM machines, small industrial equipment, motor control, and basic logic automation.
