Allen Bradley 2098-DSD-020X Ultra3000i Digital Servo Drive

Product Introduction

The Allen Bradley 2098-DSD-020X Ultra3000i Digital Servo Drive is a compact, high-performance motion control solution designed for precise single-axis positioning and indexing applications in industrial automation systems. As part of the Ultra3000 family, this drive delivers accurate digital servo control with fast response and stable operation, making it suitable for machines that require repeatable motion and high positioning accuracy.

It operates on a wide 100–240 VAC input range with a dedicated 12/24 VDC control supply, ensuring stable control performance even in complex industrial environments. With a 2 kW power rating and support for 10–30 AMP operation, the drive is optimized for medium-duty servo applications. The integrated indexing functionality allows pre-programmed motion profiles, making it ideal for automated production lines, packaging systems, CNC auxiliary axes, and material handling equipment where repeatability and precision are critical.

---

Product Specifications

---

Applications

• Automated packaging systems, where precise indexing is required for filling, labeling, and sealing operations.

• CNC auxiliary axis control, supporting accurate repetitive positioning tasks in machine tools.

• Material handling equipment, including conveyors and pick-and-place systems requiring synchronized motion.

• Industrial automation lines, where repeatable indexing improves production consistency and efficiency.

• Assembly machines, enabling precise component placement and controlled step-by-step motion sequences.

---

Advantages

• Built-in indexing function allows pre-programmed motion sequences for repeatable and efficient operation.

• High-precision digital servo control ensures accurate positioning and stable motion performance.

• Wide voltage compatibility (100–240 VAC) provides flexible installation across different industrial environments.

• Compact design (65.02 mm width) saves valuable control cabinet space while maintaining performance capability.

• Stable dual control supply (12/24 VDC) improves system reliability and control consistency.

• Strong fault protection system enhances operational safety and reduces downtime risks.

FAQ

1. What is the main difference between the 020X and standard Ultra3000i drives?
   The 020X version includes built-in indexing functionality, allowing pre-programmed motion sequences without external motion controllers.
2. What type of communication does this drive use?
   It uses a SERCOS interface for high-speed and synchronized motion control in multi-axis systems.
3. Can this drive handle indexing operations internally?
   Yes, it supports internal indexing profiles, making it suitable for repetitive and automated positioning tasks.
4. What is the power rating of this servo drive?
   The drive provides 2 kW of output power with a current range of 10–30 AMP.
5. Is the drive compatible with different AC voltage levels?
   Yes, it supports a wide input range of 100–240 VAC at 50/60 Hz.
6. What is the purpose of the 12/24 VDC supply?
   It provides stable control power for logic and communication functions independent of the main AC supply.
7. Can this drive be used in multi-axis systems?
   Yes, when used with SERCOS networks, it can be synchronized with other drives for coordinated motion.
8. What safety protections are included?
   It includes overcurrent, overvoltage, and fault detection protections to ensure safe operation.
9. What types of applications benefit most from this drive?
   Applications requiring repeatable motion such as packaging, indexing tables, and assembly systems benefit most.
10. Does the drive support precise motion control?
    Yes, its digital servo architecture ensures high precision and stable motion even under dynamic load conditions.
