Allen Bradley 2098-DSD-HV100-SE Ultra3000 Digital Servo Drive

Product Introduction

The Allen Bradley 2098-DSD-HV100-SE Ultra3000 Digital Servo Drive is a high-power motion control solution designed for demanding industrial automation systems requiring high torque, precision positioning, and stable multi-axis synchronization. As part of the Ultra3000 high-voltage series, this servo drive integrates advanced digital control technology with SERCOS communication to deliver deterministic, real-time motion performance across complex automation architectures.

With a 10 kW power class and support for high continuous and peak current output, this model is engineered for heavy-duty applications such as CNC machining centers, large robotic systems, and industrial processing equipment. It operates on a 230/460V AC input and provides 23A continuous output current with 46A peak capability, ensuring strong dynamic response under load variations. Its robust design and high reliability make it suitable for continuous industrial operation where precision and power are both critical.

---

Product Specifications

---

Applications

• Heavy-duty CNC machining systems, providing stable high-torque control for cutting, milling, and precision manufacturing operations.

• Industrial robotics, supporting coordinated motion in large robotic arms used in welding, assembly, and material handling.

• Automated production lines, ensuring synchronized multi-axis motion for high-speed manufacturing processes.

• Material handling systems, including large conveyor networks requiring strong and stable servo control.

• Metal processing and forming equipment, where high peak torque and continuous performance are essential for production stability.

---

Advantages

• High power capability (10 kW class) supports demanding industrial automation and heavy-load operations.

• High dynamic response (46A peak current) ensures strong acceleration and load-handling performance.

• SERCOS communication interface provides deterministic, high-speed synchronization across multi-axis systems.

• Flexible input voltage (230/460V AC) allows global industrial deployment.

• Robust industrial-grade design ensures long-term stability in harsh operating environments.

• Advanced servo control technology delivers precise motion, smooth operation, and consistent positioning accuracy.

FAQ

1. What is the main function of the 2098-DSD-HV100-SE servo drive?
   It provides high-power digital servo control for industrial automation systems requiring precise motion and strong torque output under dynamic load conditions.
2. What communication protocol does this drive use?
   It uses the SERCOS interface, enabling high-speed, deterministic communication for synchronized multi-axis motion control.
3. What is the difference between continuous and peak current ratings?
   The 23A continuous rating supports normal steady operation, while the 46A peak rating allows short-duration high-torque or acceleration demands.
4. What voltage range does this drive support?
   It supports 230/460V AC input, making it suitable for a wide range of industrial power systems.
5. Is this drive suitable for multi-axis synchronization?
   Yes, SERCOS communication enables precise synchronization with other servo drives in multi-axis systems.
6. What types of motors can be used with this drive?
   It is compatible with Allen-Bradley servo motors designed for the Ultra3000 platform.
7. How does the drive handle overload conditions?
   It includes built-in protection such as overcurrent, overvoltage, and thermal monitoring to prevent equipment damage.
8. Is this drive suitable for continuous industrial operation?
   Yes, it is designed for continuous-duty applications in demanding industrial environments.
9. What industries commonly use this model?
   It is widely used in CNC machining, robotics, heavy manufacturing, packaging, and material handling systems.
10. What is the role of SERCOS in this drive?
    SERCOS provides high-speed, real-time communication, ensuring precise motion coordination and improved system performance.
