Allen Bradley 2198-D032-ERS3 Kinetix 5700 Dual Axis Servo Drive

Product Introduction

The Allen Bradley 2198-D032-ERS3 Kinetix 5700 Dual Axis Servo Drive is a high-performance motion control solution designed for advanced multi-axis automation systems. As part of the Kinetix 5700 platform, this drive integrates powerful motion control, high-speed communication, and flexible configuration into a single compact unit, making it ideal for complex machine applications.

This dual-axis servo drive supports two independent motion axes within one module, significantly reducing panel space and simplifying system design. It delivers up to 4.5 kW continuous output per axis at 240V input and up to 8.9 kW per axis at 480V input, with peak output currents reaching 45.9 A per axis. The drive is engineered for demanding applications requiring precise positioning, high torque, and dynamic response.

With integrated EtherNet/IP communication and advanced motion capabilities, the Kinetix 5700 series enables seamless integration with Logix controllers. Its scalable architecture and high power density make it suitable for large, coordinated motion systems in modern industrial environments.

---

Product Specifications

---

Applications

• Multi-axis machine systems, enabling synchronized motion control for complex machinery.

• Packaging equipment, providing precise and coordinated movement for high-speed operations.

• Material handling systems, supporting accurate positioning and dynamic motion control.

• Printing and converting machines, ensuring high precision and repeatability.

• Automated assembly lines, delivering reliable and efficient multi-axis performance.

---

Advantages

• Dual-axis design reduces cabinet space and simplifies wiring compared to single-axis drives.

• High power density delivers strong performance in a compact footprint.

• Flexible voltage operation (240V/480V) supports a wide range of industrial systems.

• Integrated EtherNet/IP communication enables seamless integration with Logix platforms.

• Advanced motion control capabilities ensure precise positioning and smooth operation.

• Built-in safety features (STO) enhance system safety without additional hardware.

FAQ

1. What is the main function of the 2198-D032-ERS3 servo drive?
   It controls two servo motor axes simultaneously, providing precise motion control in industrial systems.
2. How many axes does this drive support?
   It supports two independent axes within a single module.
3. What is the output power per axis?
   It provides up to 4.5 kW per axis at 240V and 8.9 kW per axis at 480V.
4. What is the peak current rating?
   Each axis supports up to 45.9 A peak output current.
5. What communication protocol is used?
   It uses EtherNet/IP for high-speed industrial communication.
6. Is this drive suitable for multi-axis systems?
   Yes, it is specifically designed for coordinated multi-axis motion control.
7. What types of motors are compatible?
   It is compatible with servo motors used in Kinetix systems.
8. Does it include safety features?
   Yes, it includes integrated Safe Torque-Off (STO) functionality.
9. Can it operate at different voltage levels?
   Yes, it supports both 240V and 480V AC input.
10. What industries commonly use this drive?
    It is widely used in packaging, material handling, printing, and automated manufacturing systems.
