Product Introduction
The Allen-Bradley 22F-D2P5N103 PowerFlex 4M AC Drive is a compact and efficient variable frequency drive designed for small motor control applications in industrial and commercial environments. As part of the PowerFlex 4M series, it emphasizes simplicity, reliability, and ease of integration, making it well-suited for installations where space is limited and straightforward operation is required.
This model operates on a three-phase 480 VAC supply and is rated for 1 HP motors. It delivers stable speed regulation and smooth motor operation, ensuring consistent performance in light-duty applications. The drive is designed for quick commissioning, allowing users to configure basic parameters directly through the fixed keypad.
Its compact panel-mount structure makes it ideal for tight control cabinets, while the IP20 open-type enclosure is intended for protected indoor installations. The absence of an internal filter and braking IGBT provides a simplified design, offering flexibility for applications that do not require advanced braking or EMC filtering.
Product Specifications
| Parameter | Value |
|---|---|
| Model | 22F-D2P5N103 |
| Series | PowerFlex 4M |
| Input Voltage | 480 VAC |
| Phase | 3-Phase |
| Output Current | 2.5 A |
| Power Rating | 0.75 kW / 1 HP |
| Mounting Type | Panel Mount |
| Enclosure Type | IP20 / NEMA Type Open |
| Keypad | Fixed Keypad |
| Filter | Not Filtered |
| Brake Type | No Brake IGBT |
| Control Method | V/Hz Control |
| Cooling Method | Natural / Forced Air Cooling |
| Protection Features | Overcurrent, Overvoltage, Undervoltage, Thermal Protection |
| Operating Temperature | 0°C to 50°C (typical, no derating) |
| Dimensions | 174 × 72 × 136 mm |
| Weight | 1.6 kg |
Applications
● Small Conveyor Systems
Provides smooth and stable speed control for light-duty material handling operations.
● Fan and Ventilation Units
Enables basic airflow adjustment, improving efficiency in compact HVAC systems.
● Light-Duty Pump Applications
Supports consistent flow regulation in small-scale fluid handling systems.
● Compact Machinery
Ideal for space-limited equipment requiring reliable motor speed control.
● Packaging and Assembly Equipment
Ensures repeatable motion control in small automation setups.
● General Purpose Motor Control
Suitable for low-power industrial applications where simplicity and reliability are key.
Advantages
● Ultra-Compact Design
The small footprint allows installation in tight control panels and compact equipment.
● Simple and Fast Commissioning
The fixed keypad interface enables quick setup with minimal configuration effort.
● Reliable Basic Control
Provides stable V/Hz motor control, ensuring consistent performance in light-duty applications.
● Cost-Effective Solution
Simplified design without braking IGBT or filter reduces overall system cost.
● Flexible Application Use
The non-filtered configuration allows users to implement external EMC solutions if needed.
● Low Maintenance Operation
Designed for stable long-term use with minimal servicing requirements.
