The Allen-Bradley 25B-D2P3N104 PowerFlex 525 AC Drive is a compact and flexible variable frequency drive designed for precise motor control in small-scale industrial and OEM applications. As part of the PowerFlex 525 series, it offers enhanced control performance, modern communication capabilities, and efficient integration into automation systems.
This model operates on a three-phase 480 VAC supply and is rated for 1 HP motors. It provides stable speed regulation, smooth acceleration and deceleration, and reliable torque performance under varying load conditions. Despite its compact size, it delivers advanced functionality suitable for applications requiring both simplicity and performance.
The drive features a Frame Size A design, allowing easy installation in tight control cabinets. Its non-filtered configuration offers flexibility in EMC design, while embedded communication capability supports integration into PLC-based systems and industrial networks.
Product Specifications
| Parameter | Value |
|---|---|
| Model | 25B-D2P3N104 |
| Series | PowerFlex 525 |
| Input Voltage | 480 VAC |
| Phase | 3-Phase |
| Output Current | 2.3 A |
| Power Rating | 0.75 kW / 1 HP |
| Frame Size | A |
| Mounting Type | Panel Mount |
| Enclosure Type | IP20 (NEMA Type Open) |
| Filter | No Filter |
| Control Method | V/Hz Control / Sensorless Vector Control |
| Communication | Embedded EtherNet/IP |
| Cooling Method | Natural / Forced Air Cooling |
| Protection Features | Overcurrent, Overvoltage, Undervoltage, Thermal Protection |
| Operating Temperature | 0°C to 50°C (typical) |
| Dimensions | 172 × 72 × 152 mm |
| Weight | 1.1 kg |
Applications
● Small Conveyor Systems
Provides accurate and stable speed control, improving efficiency in light-duty material handling.
● Fan and Ventilation Units
Enables adjustable airflow control, supporting energy-efficient HVAC operation.
● Light-Duty Pump Applications
Ensures consistent flow regulation, enhancing process stability.
● Packaging Equipment
Supports repeatable motor performance, improving production consistency.
● Compact OEM Machinery
Ideal for space-limited equipment requiring reliable and flexible motor control.
● General Industrial Applications
Suitable for basic automation tasks where compact size and performance are required.
Advantages
● Compact Frame Size A Design
Allows easy installation in tight control panels and compact systems.
● Advanced Control Capability
Supports sensorless vector control and V/Hz control, improving motor performance.
● Integrated Network Communication
Embedded EtherNet/IP enables seamless integration with PLC and automation systems.
● Flexible EMC Configuration
The non-filtered design allows customized external filtering solutions.
● Reliable Industrial Performance
Ensures stable operation in continuous-duty environments.
● Energy Efficiency Optimization
Adjusts motor speed according to demand, reducing energy consumption.
